Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 80mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
26", lite AL-6061 tubing
Suspension Fork
Suntour XCE, 80 mm, preload adjust
Drivetrain
Rear Derailleur
Shimano RD-TY300
Front Derailleur
Shimano FD-TY300
Shift Levers
Shimano SL-RS45, 3x7-speed, revo-shifter
Cassette
Shimano MF-TZ500-7, 14-28t
Crank
Shimano FC-TY301, 42/34/24t
Bottom Bracket
Shimano BB-UN100
Chain
KMC Z7
Pedals
Marwi SP-872N
Wheels
Front Hub
Shimano dynamo hub, DH-C3000
Rear Hub
BGM Comp, quick release
Rims
Alex X18, CNC-Side
Spokes
stainless, black
Tires
Schwalbe Big Apple, reflective stripe, 50-559 Tubes: Impac AV26
Brakes
Brakes
Alloy V-Brakes
Brake Levers
V-Brake lever, adjustable reach
Cockpit
Stem
Syncros 3.0, +/-6°
Handlebar
Syncros 3.0, riserbar, width: 640 mm
Grips
Syncros MTB
Headset
BGM FP-H807B, A-Headset, semi-integrated, 1 1/8"
Seat
Saddle
Syncros M3.0
Seatpost
Syncros 3.0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 38cm | 42cm | 47cm | 51cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.66 mm | 1.6 mm | 1.57 mm | 1.55 mm |
| Bottom Bracket Height | 293 mm | 298 mm | 298 mm | 303 mm |
| Front Center | 616 mm | 628 mm | 643 mm | 660 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 86 mm | 81 mm | 83 mm | 82 mm |
| Stack | 594 mm | 595 mm | 605 mm | 614 mm |
| Reach | 357 mm | 372 mm | 385 mm | 397 mm |
| Top Tube Length | 542 mm | 552 mm | 566 mm | 582 mm |
| Seat Tube Angle | 73 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 375 mm | 420 mm | 470 mm | 510 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 140 mm | 145 mm | 155 mm | 170 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 1028 mm | 1041 mm | 1056 mm | 1074 mm |
| Bottom Bracket Drop | 50 mm | 45 mm | 45 mm | 40 mm |
| Standover Height | 656 mm | 656 mm | 656 mm | 661 mm |
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
Revox ATB 26 Lady completes the Bergamont Revox model. Bergamont launched 120 bikes of this model so far. Take a sneak peek at all Bergamont Revox bikes models from 2020, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Crosscountry bikes
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Revox ATB 26 Lady weighs 15.9 kg (35.05 lbs) and is much heavier than the average. To sum up, it’s 28.23% heavier than the average weight of Crosscountry bikes.
Overview of components
Fork
This bike has the SunTour fork installed. The fork’s travel is 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The Revox ATB 26 Lady 2020 bike is equipped with 26″ aluminum wheels when leaving the factory. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
