Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Rhythm Float 32
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29", super lite SCM Carbon
Suspension Fork
Fox 32 Rhythm, 100 mm, 15x110 mm axle
Drivetrain
Rear Derailleur
Shimano Deore XT, RD-M8100, Shadow Plus
Shift Levers
Shimano SLX, SL-M7100, 1x12 speed, rapidfire plus-shifter
Cassette
Shimano SLX, CS-M7100, 10-51t
Crank
Shimano FC-MT610, 32t
Bottom Bracket
Shimano BB-MT500, BB92, press-fit
Chain
Shimano SLX, CN-M7100
Pedals
none
Wheels
Front Hub
Syncros Silverton, 6-bolt, disc, 15x110 mm axle
Rear Hub
Syncros Silverton, Microspline, 6-bolt, disc, 12x148 mm axle
Rims
Syncros Silverton 2.5, wheelset
Spokes
Syncros Silverton 2.5
Tires
Front: Schwalbe Racing Ray, folding, Addix, 29x2.25" Rear: Schwalbe Racing Ralph, Addix, folding, 29x2.25" Tubes: Schwalbe SV19B Light
Brakes
Brakes
Shimano BR-MT500, hydraulic disc brake, SM-RT56 rotor: 180/160 mm
Brake Levers
Shimano BL-MT501, hydraulic disc brake
Cockpit
Stem
Syncros FL2.0, +/-6°
Handlebar
Syncros FL2.0, flatbar, width: 720 mm
Grips
Syncros Pro, lock-on grips
Headset
BGM F13-C, A-Headset, semi-integrated, tapered
Seat
Saddle
Syncros Tofino 2.5
Seatpost
Syncros FL2.0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.475 mm | 1.458 mm | 1.422 mm | 1.428 mm |
| Bottom Bracket Height | 302 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 651 mm | 666 mm | 687 mm | 697 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 87 mm | 84 mm | 83 mm | 81 mm |
| Stack | 599 mm | 614 mm | 623 mm | 641 mm |
| Reach | 406 mm | 421 mm | 438 mm | 449 mm |
| Top Tube Length | 575 mm | 600 mm | 620 mm | 635 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 435 mm | 480 mm | 525 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 71 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1072 mm | 1088 mm | 1109 mm | 1119 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 732 mm | 761 mm | 793 mm | 823 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Revox Pro belongs to the Bergamont Revox model. Bergamont launched 120 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Crosscountry bikes average weight
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
a bit lighter than average, Revox Pro has a weight of 11.6 kg (25.57 lbs). In short, the average Crosscountry bike weight is 6.9% higher than this one.
Revox Pro components
Fork
Bergamont Revox Pro 2020 bike is equipped with the Fox Rhythm Float 32 fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Bergamont Revox Pro 2020, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Bergamont Revox Pro has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Bergamont Revox Pro bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
