Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy
-
Groupset SLX, Shimano -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29", super lite SCM Carbon
Suspension Fork
RockShox Judy Silver, 100 mm, 15x110 mm axle
Drivetrain
Rear Derailleur
Shimano SLX, RD-M7100, Shadow Plus
Shift Levers
Shimano SLX, SL-M7100, 1x12 speed, rapidfire plus-shifter
Cassette
Shimano SLX, CS-M7100, 10-51t
Crank
Shimano FC-MT610, 32t
Bottom Bracket
Shimano BB-MT500, BB92, press-fit
Chain
Shimano SLX, CN-M7100
Pedals
none
Wheels
Front Hub
Shimano HB-MT400, centerlock, disc, 15x110 mm axle
Rear Hub
Shimano FH-MT510, centerlock, disc, 12x148 mm axle
Rims
Alex DP25, disc, eyelets, width: 25 mm
Spokes
stainless, black
Tires
Front: Schwalbe Tough Tom, Kevlarguard, 29x2.25" Rear: Schwalbe Rapid Rob, Kevlarguard, 29x2.25" Tubes: Schwalbe SV19B Light
Brakes
Brakes
Shimano BR-MT200, hydraulic disc brake, SM-RT10 rotor: 180/160 mm
Brake Levers
Shimano BL-MT200, hydraulic disc brake
Cockpit
Stem
Syncros 3.0, +/-7°
Handlebar
Syncros 3.0, flatbar, width: 720 mm
Grips
Syncros MTB
Headset
BGM F13-C, A-Headset, semi-integrated, tapered
Seat
Saddle
Syncros Tofino 2.5
Seatpost
Syncros 3.0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.475 mm | 1.458 mm | 1.422 mm | 1.428 mm |
| Bottom Bracket Height | 302 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 651 mm | 666 mm | 687 mm | 697 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 87 mm | 84 mm | 83 mm | 81 mm |
| Stack | 599 mm | 614 mm | 623 mm | 641 mm |
| Reach | 406 mm | 421 mm | 438 mm | 449 mm |
| Top Tube Length | 575 mm | 600 mm | 620 mm | 635 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 435 mm | 480 mm | 525 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 71 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1072 mm | 1088 mm | 1109 mm | 1119 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 732 mm | 761 mm | 793 mm | 823 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Revox Sport completes the Bergamont Revox model. 120 bikes variations carry this model name so far. You can easily view all of the Bergamont Revox bikes models from 2020, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Crosscountry bikes
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
equally heavier with average, Revox Sport has a weight of 12.4 kg (27.34 lbs). To sum up, it’s 0% heavier than the average weight of Crosscountry bikes.
Revox Sport components
Fork
This bike has the RockShox Judy fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, Bergamont Revox Sport 2020, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Bergamont Revox Sport is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
