Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 200mm -
Travel Rear 210mm -
Fork X Fusion
-
Groupset X5, Race Face -
Suspension Full -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
27.5", ultra strong AL-6013 tubing, 210 mm rear travel
Suspension Fork
X-Fusion RV-1, 200 mm, rebound, compression, 20x110 mm axle
Rear Shock
X-Fusion Vector Coil R, 350/400/450 lbs/in for S/M/L-XL, rebound
Drivetrain
Rear Derailleur
SRAM X5
Shift Levers
SRAM X5, 1x9-speed, trigger-shifter
Cassette
SRAM PG-950, 11-28t
Crank
Race Face Chester, 36t
Bottom Bracket
Race Face BB104.5, press-fit
Chain
KMC X9
Chain Guide
Mozart Presto, ISCG05, steel backplate, Bashguard, 32-38t
Pedals
Wellgo B087U, flatpedals
Wheels
Front Hub
BGM Pro DH, 6-bolt, disc, 20x110 mm axle
Rear Hub
BGM Pro DH, 6-bolt, disc, 12x157 mm axle
Rims
Alex MD30, width: 30 mm
Spokes
stainless, black
Tires
Front: Maxxis Minion DHF, 60 TPI, 2-ply, wired, Super Tacky, DH Casing, 27.5x2,50" Rear: Maxxis Minion DHRII, 60 TPI, 2-ply, wired, Super Tacky, DH Casing, 27.5x2,40" Tubes: Schwalbe SV21B Light
Brakes
Brakes
Shimano BR-MT420, hydraulic disc brake, 4-piston, SM-RT66 rotor: 203/203 mm
Brake Levers
Shimano BL-MT401, hydraulic disc brake
Cockpit
Stem
Syncros DH 1.5, direct-mount
Handlebar
Syncros Hixon DH 1.5, riser bar, rise: 25 mm, width: 800 mm
Grips
Syncros Pro DH dual lock-on grips
Headset
FSA Gravity 1-1, A-Headset, semi-integrated, tapered
Seat
Saddle
SDG Radar R
Seatpost
Syncros DH 2.0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.473 mm | 1.44 mm | 1.384 mm | 1.333 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 765 mm | 787 mm | 797 mm | 819 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 118 mm | 124 mm | 119 mm | 119 mm |
| Stack | 604 mm | 619 mm | 609 mm | 613 mm |
| Reach | 410 mm | 430 mm | 440 mm | 460 mm |
| Top Tube Length | 574 mm | 596 mm | 606 mm | 628 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 400 mm | 420 mm | 420 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 115 mm | 120 mm | 120 mm | 125 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1201 mm | 1223 mm | 1233 mm | 1255 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm | 10 mm |
| Standover Height | 735 mm | 732 mm | 749 mm | 747 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Straitline 7 belongs to the Bergamont Straitline model. There are 2 bikes that carry this model name. Take a sneak peek at all Bergamont Straitline bikes models from 2020, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Downhill bikes
According to our calculations, the average cost of a Downhill bike that is reliable is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Downhill bikes average weight
Downhill bikes have an average weight of 15.89 kg (35.03 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Straitline 7 weighs 18.4 kg (40.57 lbs) and is much heavier than the average. In conclusion, the average Downhill bike weighs 15.8% less than Straitline 7.
Straitline 7 components
Fork
This bike has the X Fusion fork installed. The fork’s travel is 200mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The Straitline 7 has a rear shock with a travel of 210mm. The model X-Fusion Vector Coil R is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on Straitline 7 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
