Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork DT Swiss F 535 ONE
-
Groupset XT, SLX -
Suspension Full -
Motor Bosch 85Nm mid-drive -
Battery Bosch Powertube 750Wh horizontal (The Smart System) -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bergstrom ATV C carbon frame with aluminum rear triangle, 150mm travel. Bosch 750Wh Powertube ready, Bosch CX Interface, ZS56/ZS56 Headtube with Modular Cable Routing, 148×12 (1.5P), 31.6 Seatpost
Suspension Fork
DT Swiss suspension fork F535 ONE 150, 27.5+ / 29, Crown Adjust, Boost, 110x15mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8100-SGS 12spd
Shift Levers
Shimano SLX SL-M7100 12spd
Cassette
Shimano CS-M7100-12 10-51T
Crank
FSA Direct Mount for Bosch, 34T
Bottom Bracket
Bosch, press-fit
Wheels
Rims
Front: Mavic E-DEEMAX 29 30mm, 110x15mm Boost, Centerlock, Rear: Mavic E-DEEMAX 29 30mm, 148x12mm Boost, Centerlock
Tires
Onza PORCUPINE Skinwall 29×2.60, TRC Casting, foldable
Brakes
Brakes
SRAM DB8 4-piston disc brake with 200/180 disc
Cockpit
Stem
Satori VIPER 0 45mm, Ø 31.8, matt black
Handlebar
Satori HORIZON BOW Di2 handlebar 780×31.8mm, 7mm rise
Seat
Saddle
Ergon SMA20 saddle, black
Seatpost
KS Vario seat post E20i, Ø 31.6mm x 360mm (SM 100mm, MD/LG 125mm)
Motor & Battery
Motor
Bosch CX Drive Unit, (The Smart System), 85Nm
Battery
Bosch Powertube 750Wh horizontal (The Smart System)
Charger
Bosch 4A Charger (The Smart System)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.4 mm | 1.34 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Stack | 625 mm | 630 mm | 634 mm |
| Reach | 428 mm | 450 mm | 473 mm |
| Top Tube Length | 581 mm | 604 mm | 628 mm |
| Seat Tube Angle | 76.1 ° | 76.1 ° | 76.1 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 468 mm | 468 mm | 468 mm |
| Wheelbase | 1225 mm | 1250 mm | 1273 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
ATV C 969 is a Bergstrom E Atv model. Bergstrom released 15 e-bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Bergstrom ATV 949 Carbon 2023 is the most affordable e-bike of this model and has a price of 7788$. On the other hand, Bergstrom ATV 989 RSL Carbon 2023, is the most expensive and costs 11683$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Enduro e-bikes average price
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
ATV C 969 components
Fork
The ATV C 969 comes factory-installed with the DT Swiss F 535 ONE fork. This has a travel range of 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Bergstrom ATV C 969 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ATV C 969 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Bergstrom model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
