Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork DT Swiss F 535 ONE
-
Groupset GX Eagle AXS, FSA -
Suspension Full -
Motor Bosch 85Nm mid-drive -
Battery Bosch Powertube 750Wh horizontal (The Smart System) -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bergstrom ATV C carbon frame with aluminum rear triangle, 150mm travel. Bosch 750Wh Powertube ready, Bosch CX Interface, ZS56/ZS56 Headtube with Modular Cable Routing, 148×12 (1.5P), 31.6 Seatpost
Suspension Fork
DT Swiss suspension fork F535 ONE 150, 27.5+ / 29, Crown Adjust, Boost 110x15mm
Drivetrain
Rear Derailleur
SRAM rear derailleur GX EAGLE AXS, lunar black, 12-speed
Shift Levers
SRAM shifter GX EAGLE AXS controller, black
Cassette
SRAM Cassette PG1230 EAGLE 11-50T. eMTB, Shimano Driver, 12-speed
Crank
FSA Direct Mount for Bosch, 34T
Bottom Bracket
Bosch, press-fit
Wheels
Rims
Front: Mavic E-DEEMAX 29 30mm, 110x15mm Boost, Centerlock, Rear: Mavic E-DEEMAX 29 30mm, 148x12mm Boost, Centerlock
Tires
Onza PORCUPINE Skinwall 29×2.60, TRC Casting, foldable
Brakes
Brakes
SRAM DB8 4-piston disc brake with 200/180 disc
Cockpit
Stem
Satori VIPER 0 45mm, Ø 31.8, matt black
Handlebar
Satori HORIZON BOW Di2 handlebar 780×31.8mm, 7mm rise
Seat
Saddle
Ergon SMA20 saddle, black
Seatpost
KS Vario seat post E20i, Ø 31.6mm x 360mm (SM 100mm, MD/LG 125mm)
Motor & Battery
Motor
Bosch CX Drive Unit, (The Smart System), 85Nm
Battery
Bosch Powertube 750Wh horizontal (The Smart System)
Charger
Bosch 4A Charger (The Smart System)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.4 mm | 1.34 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Stack | 625 mm | 630 mm | 634 mm |
| Reach | 428 mm | 450 mm | 473 mm |
| Top Tube Length | 581 mm | 604 mm | 628 mm |
| Seat Tube Angle | 76.1 ° | 76.1 ° | 76.1 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 468 mm | 468 mm | 468 mm |
| Wheelbase | 1225 mm | 1250 mm | 1273 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
ATV C 989 belongs to the Bergstrom E Atv model. Bergstrom released 15 e-bikes variations of this model so far. You can easily view all of the Bergstrom E Atv e-bikes models from 2022, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro e-bikes average price
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
ATV C 989 components
Fork
The DT Swiss F 535 ONE is included from the factory. It has a travel distance of 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When leaving the production line, the ATV C 989 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Bergstrom ATV C 989 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Bergstrom model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
