Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox 35 Gold RL
-
Groupset XT, SLX -
Suspension Full -
Motor Bosch 85Nm hub-drive -
Battery Bosch PowerTube 750 horizontal -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bergstrom FS ePeformance Trail aluminum frame, PowerTube Vario down tube, rear triangle with 140mm travel, Horizontal Shock Link, Postmount 180, Bosch Gen4 interface, Boost 12x148mm axle, ZS56/ZS56 1.5? headtube, 30.9mm seattube SRAM UDH interchangeable eyelet for 12×180 (1.0) Thru Axle
Suspension Fork
Rock Shox 35 Gold RL Boost 150mm suspension fork, tapered steerer, 35mm stanchions, PM 180, DebonAir air spring, Motion Control damper, Maxle Lite 110x15mm, full fender mount
Drivetrain
Rear Derailleur
Shimano XT RD-M8100 12spd
Shift Levers
Shimano SLX SL-M7100
Cassette
Shimano SLX CS-M7100 10-51T. 12spd
Crank
FSA CK-320 165mm ISIS
Bottom Bracket
Bosch, press-fit
Chain
Shimano CN-M7100
Chain Guide
optionally retrofittable
Wheels
Rims
Front: Shimano Boost 110×15 hub with Rodi TRYP 29 rim, DT Competition spokes, Rear: Shimano Boost 110×15 hub with Rodi TRYP 29 rim, DT Competition spokes
Tires
Schwalbe WICKED WILL EVO Super Trail 29?x2.35? (60-622), foldable
Brakes
Brakes
SRAM DB8 Mineral Oil 4-piston 200/180mm
Cockpit
Stem
Satoir Viper 0 ICR Stem 45mm/31.8mm
Handlebar
Satori Horizon Bow Di2 handlebar 780×31.8mm, 7mm rise
Seat
Saddle
Ergon SM10 black
Seatpost
JD dropper post R.A.D. JD-YSI05GL, Ø 30.9mm x 405mm, travel 95-125mm adjustable without tools
Motor & Battery
Motor
Bosch CX BES3 85Nm 25km/h
Battery
Bosch PowerTube 750 horizontal
Charger
36V 4A Charger, 230V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.37 mm | 1.32 mm | 1.28 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Stack | 613 mm | 613 mm | 618 mm | 627 mm |
| Reach | 428 mm | 448 mm | 468 mm | 488 mm |
| Top Tube Length | 581 mm | 602 mm | 623 mm | 646 mm |
| Seat Tube Angle | 76.7 ° | 76.7 ° | 76.7 ° | 76.7 ° |
| Seat Tube Length | 410 mm | 435 mm | 460 mm | 490 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 110 mm | 115 mm | 125 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1209 mm | 1230 mm | 1252 mm | 1231 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
AXV 849 is a Bergstrom E Axv model. There are 16 e-bikes that carry this model name. You can easily view all of the Bergstrom E Axv e-bikes models from 2023, here.
Model range prices
The most economical model, the Bergstrom AXV 829 625Wh 2023 has a starting price of 6453$. Bergstrom AXV 849 Race 750Wh 2023 on the other hand is the most expensive at 8656$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
AXV 849 components
Fork
The AXV 849 comes factory-installed with the RockShox 35 Gold RL fork. This has a travel range of 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on AXV 849 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Bergstrom AXV 849 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Bergstrom AXV 849 includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
