Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Lyrik Select+
-
Groupset XT, SLX -
Suspension Full -
Motor Bosch 85Nm hub-drive -
Battery Bosch PowerTube 750 horizontal -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bergstrom FS ePerformance Trail aluminum frame, PowerTube Vario down tube, rear triangle with 140mm travel, Horizontal Shock Link, Postmount 180, Bosch Gen4 interface, Boost 12x148mm axle, ZS56/ZS56 1.5? headtube, 30.9mm seattube SRAM UDH interchangeable eyelet for 12×180 (1.0) Thru Axle
Suspension Fork
Rock Shox LYRIK Select+ Boost 150mm suspension fork, tapered steerer, 35mm stanchions, PM 180, DebonAir+ air spring, Charger 3 RC2 damper, Maxle Stealth 110x15mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8100 12spd
Shift Levers
Shimano SLX SL-M7100
Cassette
Shimano SLX CS-M7100 10-51T. 12spd
Crank
FSA CK-320 165mm ISIS
Bottom Bracket
Bosch, press-fit
Chain
Shimano CN-M7100
Chain Guide
optionally retrofittable
Wheels
Rims
Front: Mavic E Deemax 30/29, Boost 110x15 Centerlock, Rear: Mavic E Deemax 30 / 29, Boost 148 x 12 Centerlock Microspline
Tires
Schwalbe WICKED WILL EVO Super Trail 29?x2.35? (60-622), foldable
Brakes
Brakes
SRAM DB8 Mineral Oil 4-piston 200/180mm
Cockpit
Stem
Satori Viper 0 ICR Stem 45mm/31.8mm
Handlebar
Satori Horizon Bow Di2 handlebar 780×31.8mm, 7mm rise
Seat
Saddle
Ergon SM10 black
Seatpost
JD dropper post R.A.D. JD-YSI05GL, Ø 30.9mm x 405mm, travel 95-125mm adjustable without tools
Motor & Battery
Motor
Bosch CX BES3 85Nm 25km/h
Battery
Bosch PowerTube 750 horizontal
Charger
36V 4A Charger, 230V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.37 mm | 1.32 mm | 1.28 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Stack | 613 mm | 613 mm | 618 mm | 627 mm |
| Reach | 428 mm | 448 mm | 468 mm | 488 mm |
| Top Tube Length | 581 mm | 602 mm | 623 mm | 646 mm |
| Seat Tube Angle | 76.7 ° | 76.7 ° | 76.7 ° | 76.7 ° |
| Seat Tube Length | 410 mm | 435 mm | 460 mm | 490 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 110 mm | 115 mm | 125 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1209 mm | 1230 mm | 1252 mm | 1231 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
AXV 869 is part of the Bergstrom E Axv model. Bergstrom launched 16 e-bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Bergstrom AXV 829 625Wh 2023 is the cheapest e-bike model and costs 6453$. Bergstrom AXV 849 Race 750Wh 2023 is the most expensive one and costs 8656$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
AXV 869 components
Fork
The RockShox Lyrik Select+ is included from the factory. It has a travel distance of 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the AXV 869 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The AXV 869 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Bergstrom AXV 869 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
