Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Recon Silver TK
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor Bosch hub-drive -
Battery Bosch PowerTube 625Wh horizontal -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bergstrom HT ePerformance XC aluminum frame, PowerTube Vario down tube, Postmount 160, Bosch Gen4 interface, Boost 12x148mm axle, ICR 1.5” headtube
Suspension Fork
Rock Shox Recon Silver TK Boost 29 120mm suspension fork, coil, lockout, rebound adjust, offset 51mm, PM160, axle 110x15mm
Drivetrain
Rear Derailleur
Shimano Deore RD-M5120-SGS 10spd
Shift Levers
Shimano Deore SL-M610
Cassette
Shimano Deore CS-HG500 11-41T 10spd
Crank
FSA CK-320 34T.
Bottom Bracket
Bosch, press-fit
Chain
Shimano CN-HG54 10spd
Chain Guide
optionally retrofittable
Wheels
Rims
Front: Shimano Boost 110×15 hub with Rodi TRYP 29 rim, DT Competition spokes, Rear: Shimano Boost 110×15 hub with Rodi TRYP 29 rim, DT Competition spokes
Tires
Schwalbe Racing Ray/Ralph TS 29×2.35? Tubeless Ready
Brakes
Brakes
SRAM DB8 4-piston disc brake, 180/180mm
Cockpit
Stem
JD 3D Forged Stem 35 x 31.8mm, 0°
Handlebar
Promax FlatTop handlebar 31.8 x 720mm
Seat
Saddle
Ergon SMA30 black
Seatpost
Promax 31.6mm x 400mm
Motor & Battery
Motor
Bosch Smart System CX engine
Battery
Bosch PowerTube 625Wh horizontal
Charger
Bosch 36V 4A Charger, 230V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.41 mm | 1.34 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Stack | 624 mm | 624 mm | 632 mm |
| Reach | 411 mm | 441 mm | 470 mm |
| Top Tube Length | 592 mm | 622 mm | 654 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 130 mm | 130 mm | 140 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1178 mm | 1207 mm | 1241 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
XCV 729 belongs to the Bergstrom E Xcv model. Bergstrom released 14 e-bikes variations of this model so far. You can easily view all of the Bergstrom E Xcv e-bikes models from 2022, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
XCV 729 components
Fork
The XCV 729 comes factory-installed with the RockShox Recon Silver TK fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The XCV 729 2022 e-bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Bergstrom XCV 729 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
