Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 100mm -
Fork RockShox Recon Silver TK
-
Groupset XT, SLX -
Suspension Full -
Motor Bosch hub-drive -
Battery Bosch PowerTube 625Wh horizontal -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bergstrom FS ePerformance XC aluminum frame, PowerTube Vario down tube, LCOG rear end with 100mm travel, inverted trunnion mount, Postmount 160, Bosch Gen4 interface, Boost 12x148mm axle, ICR 1.5” headtube
Suspension Fork
Rock Shox Recon Silver TK Boost 29 120mm suspension fork, coil, lockout, rebound adjust, offset 51mm, PM160, axle 110x15mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8100 12spd
Shift Levers
Shimano SLX SL-M7100
Cassette
Shimano SLX CS-M7100 10-51T. 12spd
Crank
FSA CK-320 34T.
Bottom Bracket
Bosch, press-fit
Chain
Shimano CN-M7100
Chain Guide
optionally retrofittable
Wheels
Rims
Front: Shimano Boost 110×15 hub with Rodi TRYP 29 rim, DT Competition spokes, Rear: Shimano Boost 110×15 hub with Rodi TRYP 29 rim, DT Competition spokes
Tires
Schwalbe Racing Ray/Ralph TS 29×2.35? Tubeless Ready
Brakes
Brakes
SRAM DB8 4-piston disc brake, 180/180mm
Cockpit
Stem
FSA ACR 50mm -10° Stem 31.8mm
Handlebar
FSA V-Drive Riser 740mmx31.8mm 15mm Rise
Seat
Saddle
Ergon SMA30 black
Seatpost
JD RAD 30.9mm dropper post 95-125mm travel
Motor & Battery
Motor
Bosch Smart System CX engine
Battery
Bosch PowerTube 625Wh horizontal
Charger
Bosch 36V 4A Charger, 230V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.46 mm | 1.4 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Stack | 615 mm | 626 mm | 626 mm |
| Reach | 403 mm | 428 mm | 448 mm |
| Top Tube Length | 572 mm | 598 mm | 619 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 410 mm | 445 mm | 470 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 135 mm | 140 mm | 140 mm |
| Chainstay Length | 468 mm | 468 mm | 468 mm |
| Wheelbase | 1165 mm | 1192 mm | 1212 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
XCV 849 is a Bergstrom E Xcv model. 14 e-bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry e-bikes average price
According to our calculations, the average cost of a Crosscountry e-bike that is reliable is 2453$. However, this doesn’t mean that if you spend less money on a Crosscountry e-bike, you couldn’t get a decent one. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
Bergstrom XCV 849 2022 e-bike is equipped with the RockShox Recon Silver TK fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the XCV 849 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
XCV 849 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
Dropper post
Bergstrom XCV 849 comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
