Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 100mm -
Fork RockShox SID Select
-
Groupset XT, SLX -
Suspension Full -
Motor Bosch hub-drive -
Battery Bosch PowerTube 625Wh horizontal -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bergstrom FS ePerformance XC aluminum frame, PowerTube Vario down tube, LCOG rear end with 100mm travel, inverted trunnion mount, Postmount 160, Bosch Gen4 interface, Boost 12x148mm axle, ICR 1.5” headtube
Suspension Fork
Rock Shox SID Select 29 Boost 120mm suspension fork, tapered steerer, 35mm tapered stanchions, offset 44mm, PM180, DebonAir, Charger RL damper, Maxle Stealth 110x15mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8100 12spd
Shift Levers
Shimano SLX SL-M7100
Cassette
Shimano SLX CS-M7100 10-51T. 12spd
Crank
FSA CK-320 34T.
Bottom Bracket
Bosch, press-fit
Chain
Shimano CN-M7100
Chain Guide
optionally retrofittable
Wheels
Rims
Front: System impeller 29 / 30mm, Boost 110 x 15 Centerlock, Rear: System impeller 29 / 30mm, Boost 148 x 12 Centerlock Microspline
Tires
Schwalbe Racing Ray/Ralph TS 29×2.35? Tubeless Ready
Brakes
Brakes
SRAM DB8 4-piston disc brake, 180/180mm
Cockpit
Stem
FSA ACR 50mm -10° Stem 31.8mm
Handlebar
FSA V-Drive Riser 740mmx31.8mm 15mm Rise
Seat
Saddle
Ergon SMA30 black
Seatpost
JD RAD 30.9mm dropper post 95-125mm travel
Motor & Battery
Motor
Bosch Smart System CX engine
Battery
Bosch PowerTube 625Wh horizontal
Charger
Bosch 36V 4A Charger, 230V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.46 mm | 1.4 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Stack | 615 mm | 626 mm | 626 mm |
| Reach | 403 mm | 428 mm | 448 mm |
| Top Tube Length | 572 mm | 598 mm | 619 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 410 mm | 445 mm | 470 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 135 mm | 140 mm | 140 mm |
| Chainstay Length | 468 mm | 468 mm | 468 mm |
| Wheelbase | 1165 mm | 1192 mm | 1212 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
XCV 869 completes the Bergstrom E Xcv model. 14 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry e-bikes
If you want an acceptable Crosscountry e-bike you should know that the average price is 2453$. However, even though the average price of a Crosscountry e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
XCV 869 components
Fork
Bergstrom XCV 869 2022 e-bike is equipped with the RockShox SID Select fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on XCV 869 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Bergstrom XCV 869 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Bergstrom XCV 869 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
