Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Belador Allroad HPR, Gravel type 1-2 Geometry BGC, filed and polished Aluminum 3BS 6061 Hydroforming, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2", Flat Mount System brake, 700x42 maximun tyre, Thru axle 12x142mm, weight 1750g
Suspension Fork
FORK BELADOR ALLROAD EVO, full carbon, internal cable system ICS2, 1-1/8" - 1-1/2" Tappered, Flat Mount System brake max. 160mm disc, 700x44 maximun tyre, Flip-chip adust 45-51mm rake, 405mm axle-crown, Thru axle 12x100mm, weight 500g
Rear Shock
FOX Factory FLOAT DPS 3P Trunnion 165x45, Kashima Coat, Float Evol Air 3P Lockout remote 3 Position, weight 221g, 113mm travel
Drivetrain
Rear Derailleur
SRAM RD APEX EAGLE D1 MAX 52T
Cassette
SRAM XG1210, 11-50T, weight 730g
Crank
SRAM APEX D1 AL, DUB WIDE, 44T, 170-172,5-175
Chain
SRAM APEX CN-APX-D1
Wheels
Rims
Mavic Allroad, Aluminum S6000 rim, height 22mm, internal width 23 mm, max. weight 120kg, weight 1890g
Tires
Vittoria Terreno Dry 40, Fold full, weight 698g
Brakes
Brakes
SRAM APEX SJD Shift-Brake System Flatmount 160/F and 160/R Centerlock Rotor
Brake Levers
SRAM APEX D1 SJD Shift-Brake System
Cockpit
Handlebar
Avanforce 3 Gravel, Alloy 6061, /400, 420, 440mm, weight 330g
Seat
Saddle
Selle Royal 2058, Steel rails, width 285mm, width 145mm, weight 315g
Seatpost
Avanforce AF3, Aluminum 6061, 0 offset, 27,2 x 350mm, weight 255g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.47 mm | 1.49 mm | 1.48 mm |
| Bottom Bracket Height | 259 mm | 259 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 592 mm | 599 mm | 605 mm | 614 mm | 630 mm |
| Rake | 41 mm | 41 mm | 41 mm | 41 mm | 41 mm |
| Trail | 80 mm | 77 mm | 73 mm | 70 mm | 67 mm |
| Stack | 527.9 mm | 543.9 mm | 558.9 mm | 577.1 mm | 596.2 mm |
| Reach | 368.4 mm | 373.7 mm | 379.1 mm | 388.1 mm | 402.3 mm |
| Top Tube Length | 517 mm | 537.2 mm | 547 mm | 561.4 mm | 581.3 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 484 mm | 508 mm | 532 mm | 556 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 100 mm | 115 mm | 131 mm | 148 mm | 166 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1003 mm | 1009 mm | 1016 mm | 1026 mm | 1041 mm |
| Bottom Bracket Drop | 77 mm | 77 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
BELADOR ALLROAD HPR 5 belongs to the Berria Belador model. Berria released 65 bikes variations of this model so far. You can easily view all of the Berria Belador bikes models from 2024, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Endurance bikes
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the BELADOR ALLROAD HPR 5 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
