Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Fork RockShox -
Groupset Rival XPLR AXS -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Belador ALLROAD, Geometry BGC, Rear progressive suspension 26mm, Full carbon HM2X, Triple monocoque, Resin Matrix Nanotech, BB86 botton bracket, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2"- 1-1/2", Flat Mount System brake,700x44 /
Suspension Fork
Rock Shox Rydy ULT 700, Damper Type Charger Race Day, Rake 51mm, 30mm travel
Drivetrain
Rear Derailleur
SRAM RIVAL XPLR ETAP AXS D1 MAX 44T Electronic Shift System
Cassette
SRAM RIVAL XPLR XG1251, 10-44
Crank
SRAM RIVAL 1 DUB WIDE Crankset 40 T, 170-172,5-175mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM RIVAL CN-RIV-D1
Wheels
Rims
Fulcrum Rapid Red 900, alloy, Rim 22 mm 1950g - 28 (front) 28 (rear), J SPokesSpokes 2.0 mm
Tires
Vittoria Terreno Dry 38C, TNT, 120 TPI, weight 698g
Brakes
Brakes
SRAM RIVAL eTap AXS HRD Shift-Brake System Flatmount 160/F and 140/R Pace line Rotor
Brake Levers
SRAM RIVAL eTap AXS HRD Shift-Brake System Electronic Shift System
Cockpit
Stem
Avanforce ICS2, -7°, Ø31,8, 90-100-110-120mm
Handlebar
Avanforce UD Carbon, wide 400, 420, 440mm
Seat
Saddle
Selle Italia MODEL X BB FEC, Alloy rails, wide 143mm
Seatpost
SRAM REVERB AXS XPLR, 0 offset, 27,2 x 350mm, weight 549g, 75mm travel.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.43 mm | 1.43 mm | 1.45 mm | 1.46 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 593 mm | 607 mm | 620 mm | 630 mm | 642 mm |
| Rake | 44 mm | 44 mm | 46 mm | 45 mm | 45 mm |
| Trail | 77 mm | 73 mm | 68 mm | 66 mm | 63 mm |
| Stack | 527 mm | 542 mm | 559 mm | 579 mm | 597 mm |
| Reach | 366 mm | 380 mm | 390 mm | 399 mm | 410 mm |
| Top Tube Length | 517 mm | 532 mm | 547 mm | 567 mm | 587 mm |
| Seat Tube Angle | 75.1 ° | 74.8 ° | 74.5 ° | 74.2 ° | 73.9 ° |
| Seat Tube Length | 460 mm | 484 mm | 508 mm | 532 mm | 556 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 98 mm | 113 mm | 129 mm | 146 mm | 164 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 992 mm | 1007 mm | 1020 mm | 1030 mm | 1042 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
BELADOR ALLROAD LTD is a Berria Belador model. 65 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Berria BELADOR 6 2022 is the most affordable bike of this model and has a price of 2760$. On the other hand, Berria BELADOR BR LTD 2022, is the most expensive and costs 8175$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Endurance bikes average price
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
BELADOR ALLROAD LTD components
Fork
The fork installed on this bike is the RockShox model. The travel on this model is mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
BELADOR ALLROAD LTD has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Berria BELADOR ALLROAD LTD 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Berria BELADOR ALLROAD LTD has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
BELADOR ALLROAD LTD comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the BELADOR ALLROAD LTD. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
