Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
154cm - 166cm
SM
164cm - 177cm
MD
175cm - 186cm
LG
184cm - 192cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Belador 5 BR DISC, Racing Geometry BGC Aero Shape Efficiency (ASE), Full carbon HM3X, Triple monocoque, Resin Matrix Nanotech, BB86 botton bracket, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2"- 1-1 /2", Flat Mount System brake, 700x34 maximun tire, Thru axle 12x142mm Speed Release type, weight 820g
Suspension Fork
Belador Blade 5 full carbon fork.
Drivetrain
Rear Derailleur
SRAM FORCE eTap AXS Electronic Shift System
Shift Levers
SRAM FORCE eTap AXS HRD Shift-Brake System Electronic Shift System
Cassette
SRAM FORCE XG1270, 10-33T
Crank
SRAM FORCE Crankset 48/35T, 170-172.5-175mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM FORCE PC-1170
Wheels
Rims
FULCRUM 800 DB, Aluminum, TLR, Rim 34mm, 19mm internal wide 1960g
Tires
Rubino IV 28-622/ Tubeless ready /GRAPHENE 2.0
Brakes
Brakes
SRAM FORCE eTap AXS HRD Shift-Brake System Flatmount 160/F and 140/R Pace line Rotor
Cockpit
Stem
Avanforce ICS2, -7°, Ø31.8, 90-100-110-120mm
Handlebar
Avanforce UD Carbon, wide 400, 420, 440mm
Seat
Saddle
Selle Italia MODEL X BB FEC, Alloy rails, wide 143mm
Seatpost
Belador 5 BR SP, UD Carbon, 15mm offset, ISP technology, weight 129g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.42 mm | 1.42 mm | 1.44 mm | 1.45 mm |
| Bottom Bracket Height | 262 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 574 mm | 588 mm | 599 mm | 609 mm | 621 mm |
| Rake | 43 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 71 mm | 69 mm | 66 mm | 63 mm | 60 mm |
| Stack | 527 mm | 542 mm | 559 mm | 579 mm | 597 mm |
| Reach | 369 mm | 383 mm | 393 mm | 402 mm | 413 mm |
| Top Tube Length | 515 mm | 534 mm | 552 mm | 570 mm | 590 mm |
| Seat Tube Angle | 75.1 ° | 74.7 ° | 74.3 ° | 73.9 ° | 73.5 ° |
| Seat Tube Length | 435 mm | 475 mm | 505 mm | 535 mm | 568 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 125 mm | 141 mm | 157 mm | 176 mm | 193 mm |
| Chainstay Length | 404 mm | 404 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 966 mm | 981 mm | 994 mm | 1004 mm | 1016 mm |
| Bottom Bracket Drop | 74 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 154 cm | 164 cm | 175 cm | 184 cm | 185 cm |
| Rider Max Height | 166 cm | 177 cm | 186 cm | 192 cm | 195 cm |
About this model
BELADOR BR 9 is a Berria Belador model. 65 bikes variations carry this model name so far. You can easily view all of the Berria Belador bikes models from 2022, here.
Model range prices
The most economical model, the Berria BELADOR 6 2022 has a starting price of 2760$. Berria BELADOR BR LTD 2022 on the other hand is the most expensive at 8175$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5202$. In conclusion, this bike price is 121.74% more expensive than the price of the average Endurance bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
BELADOR BR 9 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The BELADOR BR 9 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Berria BELADOR BR 9 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 154 cm – 195 cm (5.05 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
