Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED eTAP -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BR DISC Belador frame made of carbon HM3X made of CNT Nanotech resin and monocoque structure / competition BGC geometry with Power Efficiency system / Active Stay braces / oversized OHS steering / Flat Mount / BB86 brake system / internal wiring / frame weight gr. 820
Suspension Fork
BLADE HELIUM DISC
Drivetrain
Rear Derailleur
SRAM Red eTap AXS
Shift Levers
SRAM Red eTap AXS, HRD
Cassette
SRAM XG-1290 10-33t 12-Speed
Crank
SRAM Red Dub 46X33t, 170 / 172,5 / 175 mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM Red eTap AXS
Wheels
Rims
2,000 gr
Spokes
24 (front) / 24 (rear)
Tires
Vittoria Zaffiro 25-622
Brakes
Brakes
SRAM Red eTap AXS, 160mm Front, 140mm Rear
Cockpit
Stem
Zipp Service Course SL Ø31.8 mm, -6º, 1-1 / 8 ", aluminum 7075 90/100/110/120 mm
Handlebar
Zipp 70 Ergo Carbon handlebar, UD carbon, 70mm reach, 128mm drop, 31.8mm diameter
Seat
Saddle
SADDLE SAEVID ALIEN braided carbon rails 7X9 mm, width 142 mm and length 275 mm
Seatpost
Zipp SL Speed Ø27.2mm, 350mm, 25mm offset, carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.38 mm | 1.4 mm | 1.42 mm | 1.44 mm |
| Bottom Bracket Height | 264 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 572 mm | 579 mm | 586 mm | 594 mm | 605 mm |
| Rake | 48 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 59 mm | 57 mm | 56 mm | 55 mm |
| Stack | 505.9 mm | 521.8 mm | 537.2 mm | 552.3 mm | 571.7 mm |
| Reach | 365.3 mm | 378.9 mm | 384.5 mm | 389.6 mm | 395.9 mm |
| Top Tube Length | 505.1 mm | 529 mm | 542 mm | 556 mm | 570 mm |
| Seat Tube Angle | 74.7 ° | 74 ° | 73.8 ° | 73.5 ° | 73.2 ° |
| Seat Tube Length | 480 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 72.6 ° | 72.9 ° | 73.1 ° | 73.2 ° |
| Head Tube Length | 110 mm | 125 mm | 140 mm | 155 mm | 175 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 966 mm | 973 mm | 981 mm | 989 mm | 1000 mm |
| Bottom Bracket Drop | 72 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
BELADOR BR DISC LTD is part of the Berria Belador model. Berria released 65 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Berria BELADOR 7 2020 is the most economical model, with a starting price of 1910$. Berria BELADOR BR DISC LTD 2020 on the other hand costs 6688$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Berria released this model in 2020, its price was 6688$. If we compare this with the average Endurance bike cost we notice that the price is 185.08% higher.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
BELADOR BR DISC LTD has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on BELADOR BR DISC LTD are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Berria BELADOR BR DISC LTD has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
