Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival XPLR AXS, Rival AXS -
Suspension Rigid -
Motor Polini 250W 75Nm mid-drive -
Battery POLINI 500Wh 36V 13,8Ah, 2620g -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Belador Hybrid, Endurance Geometry BGC Aero Shape Efficiency (ASE), Full carbon HM2X, Triple monocoque, Resin reinforced Mach-R, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/8" - 1-1/2", Flat Mount System brake, 700x30 maximun tyre, Thru axle 12x142mm, weight 2200g
Suspension Fork
Belador Hybrid 2 full carbon fork, internal cable system ICS2, 1-1/8" - 1-1/2" Tappered head tube compatible, Flat Mount System brake, 700x32 maximun tyre, Thru axle 12x100mm, weight 430g
Drivetrain
Rear Derailleur
SRAM RIVAL XPLR ETAP AXS D1 MAX 44T Electronic Shift System
Front Derailleur
SRAM RIVAL eTap AXS Electronic Shift System
Cassette
SRAM RIVAL XPLR XG1251, 10-44
Crank
Rotor e-Vegast, TDS, OCP, 44 T, 170-175mm
Chain
SRAM RIVAL CN-RIV-D1
Wheels
Rims
FULCRUM 800 DB, Aluminium, TLR, Rim 34 mm, 19 mm internal wide 1960g - 28 (front) 28 (rear), J Pull Spokes
Tires
Rubino IV 30-622, Tubeless Ready, GRAPHENE 2.0, weight 370g
Brakes
Brakes
SRAM RIVAL eTap AXS HRD Shift-Brake System Flatmount 160/F and 140/R Pace line Rotor
Brake Levers
SRAM RIVAL eTap AXS HRD Shift-Brake System Electronic Shift System
Cockpit
Stem
FSA NS SR ACR Integration System Ø31,8 mm, -6°, 1-1/8", Aluminum 6061, 80-90-100-110-120mm
Handlebar
Avanforce UD Carbon, wide 400, 420, 440mm
Seat
Saddle
Selle Italia MODEL X BB FEC, Alloy rails, wide 143mm
Seatpost
Belador Hybrid Integrated Concept Carbon, 20 mm offset
Motor & Battery
Motor
POLINI EP3+ Tuning BR HYBRID Engine Control Unit, Nominal performances 250W - 75Nm, Peak performance 500W, 137mm bottom bracket width, weight 2950g
Battery
POLINI 500Wh 36V 13,8Ah, 2620g
Charger
Polini EP3 Charger UE 220-240V 3A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.37 mm | 1.41 mm | 1.41 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 586 mm | 596 mm | 602 mm | 616 mm |
| Rake | 54 mm | 54 mm | 54 mm | 55 mm |
| Trail | 52 mm | 50 mm | 49 mm | 46 mm |
| Stack | 524 mm | 534.3 mm | 554.3 mm | 569.5 mm |
| Reach | 382 mm | 391.4 mm | 393.4 mm | 405 mm |
| Top Tube Length | 517 mm | 539 mm | 557 mm | 579 mm |
| Seat Tube Angle | 75.5 ° | 74.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 72.25 ° | 72.5 ° | 72.75 ° | 73 ° |
| Head Tube Length | 120 mm | 130 mm | 150 mm | 165 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 998 mm | 1008 mm | 1014 mm | 1028 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
BELADOR HYBRID XPLR 8 is a Berria E Belador model. 11 e-bikes variations carry this model name so far. Take a sneak peek at all Berria E Belador e-bikes models from 2023, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance e-bikes average price
If you want to purchase a solid Endurance e-bike, it is important to know that the average cost is 3800$. However, this doesn’t mean that if you spend less money on an Endurance e-bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
BELADOR HYBRID XPLR 8 components
Fork material
BELADOR HYBRID XPLR 8 has a carbon fork, so, it’s a great addition to the e-bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Berria BELADOR HYBRID XPLR 8 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Berria BELADOR HYBRID XPLR 8 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
BELADOR HYBRID XPLR 8 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, you can easily find one that suits you.
