Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy
-
Groupset NX Eagle, Truvativ -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bravo 5 carbon HM1X frame built in Matrix Nanotech resin and Triple monocoque structure / 29 "BGC cross country geometry / Active Stay straps / asymmetric chainstays / oversized O2HS steering / Post Mounted brake system / BB92 / internal wiring routing / boost 148 x12 / box weight 1,150 gr
Suspension Fork
Rock Shox Judy RL Air 29 ", Poploc remote control, rebound adjustment, Solo Air cartridge, tapered head tube and aluminum crown, 15x110mm Maxle Stealth thru-axle, 100mm of travel, 51mm advance
Drivetrain
Rear Derailleur
SRAM NX EAGLE 12V
Shift Levers
SRAM NX EAGLE Trigger 12V
Cassette
SRAM PG-1210, 11-50T, 12V
Crank
Truvativ 6K Eagle, 34T, 170/175 mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM CN-SX EAGLE, 12v
Wheels
Rims
1,875 gr
Spokes
28 (front) / 28 (rear)
Tires
Vittoria Barzo 29 "x2.25 Rigid
Brakes
Brakes
SHIMANO MT200, hydraulic disc brake, FRONT 180mm REAR 160mm, aluminum lever
Cockpit
Stem
Token AL7075 Ø31.8 mm, -17º, 1-1 / 8 ", aluminum 6061, 80/90/100 / 110mm
Handlebar
Token +/- 5mm Handlebar, 6061 Aluminum, 720mm width, 9 degree tilt, 31.8mm diameter
Seat
Saddle
Selle Royal Performance saddle, light manganese rails, width 143 mm and length 278 mm
Seatpost
SP TOKEN 27.2mm, 400mm, 25mm offset, 6061 aluminum
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.47 mm | 1.39 mm | 1.33 mm |
| Bottom Bracket Height | 308 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 660 mm | 673 mm | 702 mm | 721 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 89 mm | 86 mm | 86 mm | 82 mm |
| Stack | 599.4 mm | 601.7 mm | 606.2 mm | 613.2 mm |
| Reach | 393.2 mm | 410.3 mm | 437.4 mm | 459.5 mm |
| Top Tube Length | 555 mm | 578 mm | 612 mm | 642 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 425 mm | 470 mm | 520 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 69.5 ° | 70 ° |
| Head Tube Length | 93 mm | 95 mm | 100 mm | 105 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 429 mm |
| Wheelbase | 1077 mm | 1091 mm | 1120 mm | 1142 mm |
| Bottom Bracket Drop | 66 mm | 64 mm | 64 mm | 64 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
BRAVO 5 belongs to the Berria Bravo model. 36 bikes variations carry this model name so far. Take a sneak peek at all Berria Bravo bikes models from 2020, by clicking here.
Model range prices
The most economical model, the Berria BRAVO 4 2020 has a starting price of 1485$. Berria BRAVO BR LTD 2020 on the other hand is the most expensive at 6370$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Berria BRAVO 5 price was 1804$. In conclusion, this bike price is 5.6% lower than the price of the average Crosscountry bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
BRAVO 5 components
Fork
The RockShox Judy is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
BRAVO 5 has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Berria BRAVO 5 2020, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The BRAVO 5 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, it won’t take much to find one that’s right for you.
