Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset NX Eagle, X1 -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
150cm - 165cm
SM
160cm - 175cm
MD
170cm - 185cm
LG
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bravo 5 EVO, XCO Racing Geometry BGC 29", Full carbon HMR2X, Triple monocoque, Resin Matrix Nanotech CNT, BB92 botton bracket, Active Stay, Asymmetric, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2", Post Mounted brake PMS, 29"x2.35 maximun tire, BOOST Thru axle 12x148mm, Dropout SRAM UDH, weight 1150g
Suspension Fork
Rock Shox RECON RL, Motion Control Damper, 15x110mm Maxle Stealth, Tapered steerer, Remote Lockout, Rake 51, 32mm straight wall aluminum Fast Black, weight 2353g, 100mm travel
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12 Speed
Shift Levers
SRAM NX Eagle Trigger
Cassette
SRAM XG1210, 11-50T
Crank
SRAM X1 DUB Eagle Boost 34T 170-175mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM SX Eagle CN-EAGL-SX-A1
Wheels
Rims
Fulcrum Red Zone 99, alloy, 23mm
Spokes
28 (front) 28 (rear), Straight Pull Spokes
Tires
Vittoria Barzo 2.25X 29 /Rigid Bead
Brakes
Brakes
SRAM LEVEL Disc 180/F and 160/R
Cockpit
Stem
Forward force, -6°, Ø31.8, 80-90-100mm
Handlebar
Advanceforce 2, 31.8mm, wide 740mm
Seat
Saddle
Fizik Taiga alloy rail
Seatpost
Advanceforce 0 offset, 27.2 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.47 mm | 1.39 mm | 1.33 mm |
| Bottom Bracket Height | 308 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 662 mm | 675 mm | 704 mm | 721 mm |
| Rake | 49 mm | 49 mm | 49 mm | 47 mm |
| Trail | 94 mm | 91 mm | 91 mm | 89 mm |
| Stack | 599.4 mm | 601.7 mm | 606.2 mm | 613.2 mm |
| Reach | 393.2 mm | 410.3 mm | 437.4 mm | 459.5 mm |
| Top Tube Length | 555 mm | 578 mm | 612 mm | 642 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 425 mm | 470 mm | 520 mm |
| Head Tube Angle | 68.6 ° | 69.1 ° | 69.1 ° | 69.6 ° |
| Head Tube Length | 93 mm | 95 mm | 100 mm | 105 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 429 mm |
| Wheelbase | 1077 mm | 1091 mm | 1120 mm | 1142 mm |
| Bottom Bracket Drop | 66 mm | 64 mm | 64 mm | 64 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 170 cm | 180 cm |
| Rider Max Height | 165 cm | 175 cm | 185 cm | 198 cm |
Model Overview
BRAVO 5 belongs to the Berria Bravo model. Berria released 36 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Berria BRAVO SPORT 2022 is the most affordable bike of this model and has a price of 1804$. On the other hand, Berria BRAVO 9 2022, is the most expensive and costs 3928$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2123$. Comparing this to the average Crosscountry bike price, we see that the price is 11.44% higher.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
BRAVO 5 components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When it comes to wheels, the BRAVO 5 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Berria BRAVO 5 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 150 cm – 198 cm (4.92 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
