Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork RockShox SID Ultimate
-
Groupset GX Eagle AXS, X1 -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bravo 5 EVO, XCO Racing Geometry BGC 29", Full carbon HMR2X, Triple monocoque, Resin Matrix Nanotech CNT, BB92 botton bracket, Active Stay, Asymmetric, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2", Post Mounted brake PMS, 29"x2.35 maximun tyre, BOOST Thru axle 12x148mm, Dropout SRAM UDH, weight 1150g
Suspension Fork
Rock Shox SID Ultimate, Damper Type Charger Race Day, 15x110mm Maxle Stealth, Rake 44mm, Tapered steerer, 35 mm straight wall aluminium Fast Black, Lockout remote, weight 1537 g, 120mm travel
Drivetrain
Rear Derailleur
SRAM GX AXS 12 Speed
Cassette
SRAM XG1275, 10-52T
Crank
SRAM X1 DUB Eagle Boost 34T 170-175mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM GX Eagle CN-EAGL-GX-A1
Wheels
Rims
FULCRUM RED ZONE 99, alloy, 23 mm internal wide 1875g - 28 (front) 28 (rear), Straight Pull Spokes
Tires
Vittoria Barzo 2.25"X 29", Tubeless Ready, GRAPHENE 2.0 120 TPI, weight 660g
Brakes
Brakes
SRAM LEVEL TLM Disc 180/F 160/R
Brake Levers
SRAM GX AXS EAGLE Controller
Cockpit
Handlebar
Avanforce UD carbon, 31,8mm, wide 740mm, Backsweep 5°, Upsweep 3°
Seat
Saddle
Fizik Taiga alloy rail
Seatpost
Avanforce 0 offset, 27,2 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.47 mm | 1.39 mm | 1.33 mm |
| Bottom Bracket Height | 308 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 662 mm | 675 mm | 704 mm | 726 mm |
| Rake | 49 mm | 49 mm | 49 mm | 52 mm |
| Trail | 94 mm | 91 mm | 91 mm | 84 mm |
| Stack | 599.4 mm | 601.7 mm | 606.2 mm | 613.2 mm |
| Reach | 393.2 mm | 410.3 mm | 437.4 mm | 459.5 mm |
| Top Tube Length | 555 mm | 578 mm | 612 mm | 642 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 425 mm | 470 mm | 520 mm |
| Head Tube Angle | 68.6 ° | 69.1 ° | 69.1 ° | 69.6 ° |
| Head Tube Length | 93 mm | 95 mm | 100 mm | 105 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1077 mm | 1091 mm | 1120 mm | 1142 mm |
| Bottom Bracket Drop | 66 mm | 64 mm | 64 mm | 64 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
BRAVO LTD completes the Berria Bravo model. Berria launched 36 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
Berria BRAVO LTD 2023 bike is equipped with the RockShox SID Ultimate fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Berria BRAVO LTD 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Berria BRAVO LTD is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
BRAVO LTD comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, finding one for you shouldn’t be a problem.
