Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 110mm -
Travel Rear 105mm -
Fork Fox Factory Float 34
-
Groupset GX Eagle AXS, X1 -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
153cm - 170cm
MD
168cm - 185cm
LG
183cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mako 3, XCO Racing Geometry BGC, kinematic XCO WC 105mm, Full carbon HMR2X, Triple moncoque, Resin Matrix Nanotech CNT, full ball bearings ISB VMAX, BB92 botton bracket, Active Stay, Asymmetric, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2", Post Mounted brake PMS, 29"x2.35 maximun tire, BOOST Thru axle 148x12, Fox Live Valve ready, weight 1810g
Suspension Fork
FOX 34 SC Float Factory Air, Kashima FIT4, 15x110mm Kabolt, Axle 44mm offset, Tapered steerer, Reb. Adj. Lockout remote 3 Position, weight 1623g, 110mm travel
Rear Shock
FOX FACTORY FLOAT DPS BERRIA MAKO 3 WC XCO Tuning, EVOL SV 3 POS adjustment, Trunion 165X45mm, weight 244g, 105mm travel
Drivetrain
Rear Derailleur
SRAM GX AXS 12 Speed
Shift Levers
SRAM GX AXS EAGLE Controller
Cassette
SRAM XG1275, 10-52T
Crank
SRAM X1 DUB Eagle Boost 34T 170-175mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM GX Eagle CN-EAGL-GX-A1
Wheels
Rims
Fulcrum Red Zone 99, alloy, 23mm
Spokes
28 (front) 28 (rear), Straight Pull Spokes
Tires
Vittoria Barzo 2.25"X 29" / Tubeless ready /GRAPHENE 2.0 / 120 TPI
Brakes
Brakes
SRAM LEVEL TLM Disc 180/F 160/R
Cockpit
Stem
Forward force, -6°, Ø31.8, 80-90-100mm
Handlebar
Avanforce UD carbon, 31.8mm, wide 740mm, Backsweep 5°, Upsweep 3°
Seat
Saddle
Fizik Taiga alloy rail
Seatpost
Advanceforce 0 offset, 31.6 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.442 mm | 1.366 mm | 1.299 mm |
| Bottom Bracket Height | 328 mm | 328 mm | 328 mm |
| Front Center | 680 mm | 708 mm | 742 mm |
| Rake | 45 mm | 40 mm | 40 mm |
| Trail | 98 mm | 103 mm | 103 mm |
| Stack | 598.6 mm | 607.9 mm | 617.2 mm |
| Reach | 415 mm | 445 mm | 475 mm |
| Top Tube Length | 571.9 mm | 605.6 mm | 656 mm |
| Seat Tube Angle | 74.2 ° | 74 ° | 73.7 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm |
| Head Tube Angle | 68.7 ° | 68.7 ° | 68.7 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1110 mm | 1139 mm | 1173 mm |
| Bottom Bracket Drop | 46 mm | 46 mm | 46 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 153 cm | 168 cm | 183 cm |
| Rider Max Height | 170 cm | 185 cm | 200 cm |
About this model
MAKO 9 is a Berria Mako model. Berria released 64 bikes variations of this model so far. Take a sneak peek at all Berria Mako bikes models from 2022, by clicking here.
Model range prices
Berria MAKO 4 2022 is the cheapest bike model and costs 3503$. Berria MAKO BR LTD 2022 is the most expensive one and costs 9343$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Berria MAKO 9 price was 5733$. If we compare this with the average Crosscountry bike cost we notice that the price is 200.94% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
MAKO 9 components
Fork
The MAKO 9 comes factory-installed with the Fox Factory Float 34 fork. This has a travel range of 110mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is FOX FACTORY FLOAT DPS BERRIA MAKO 3 WC XCO Tuning, with a travel distance of 105mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on MAKO 9 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 153 cm – 200 cm (5.02 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
