Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 110mm -
Travel Rear 105mm -
Fork Fox Factory Float 34
-
Groupset XX1 Eagle AXS, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mako 3 frame in carbon UHM3X built in CNt Nanotech resin and Monocoque structure / WC geometry cross country / Active Stay braces / ASYM asymmetric chainstays / oversized OH2S steering / PMS post mounted brake system / Full carbon VMAX bearings / box BB92 bottom bracket / ICS2 internal wiring / boost 148x12 / 105 mm travel / swingarm weight, carriage and frame 1515 gr.
Suspension Fork
FOX 34 SC Float Factory Air / Kashima FIT4 / 15x110mm Kabolt / axle 44mm offset / tapered steerer / Reb. Adj. / Lockout 110mm travel / Weight 1623gr./ Remote 3 Position DT Swiss Two in One
Drivetrain
Rear Derailleur
SRAM XX1 Eagle AXS / 12 SpeedWireless Electronic Shift System
Shift Levers
SRAM Eagle AXS Controller
Cassette
SRAM XG1275 / 10-52 T
Crank
SRAM X1 DUB Eagle Boost Carbon crankarm / 34T
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM CN GX Eagle
Wheels
Rims
1700 g
Spokes
24 (front) 24 (rear), Straight Pull Spokes 2-1.6 mm
Tires
Vittoria Barzo 2.25 "X 29" / Tubeless ready / GRAPHENE 2.0 / 120 TPI
Brakes
Brakes
SRAM Level TLM Disc / tool free reach adj / 180 / F and 160 / R 6T rotor CL (FULCRUM)
Cockpit
Stem
Avanforce AL 7075 / -17º / Ø31.8 / 80,90,100,110
Handlebar
Avanforce UD Carbon 720 mm
Seat
Saddle
Fizik Tundra M7 / manganese rails
Seatpost
Avanforce Aluminum 7075/0 offset / 31.6 x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1 mm | 1.366 mm | 1.299 mm |
| Bottom Bracket Height | 328 mm | 328 mm | 328 mm |
| Front Center | 680 mm | 708 mm | 742 mm |
| Rake | 111 mm | 40 mm | 40 mm |
| Trail | 27 mm | 103 mm | 103 mm |
| Stack | 415 mm | 607.9 mm | 617.2 mm |
| Reach | 415 mm | 445 mm | 475 mm |
| Top Tube Length | 571.9 mm | 605.6 mm | 656 mm |
| Seat Tube Angle | 74.2 ° | 74 ° | 73.7 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm |
| Head Tube Angle | 68.7 ° | 68.7 ° | 68.7 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1110 mm | 1139 mm | 1173 mm |
| Bottom Bracket Drop | 46 mm | 46 mm | 46 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
MAKO BR 9 belongs to the Berria Mako model. Berria released 64 bikes variations of this model so far. You can easily view all of the Berria Mako bikes models from 2021, here.
Model range prices
Berria MAKO SPORT 2021 is the cheapest bike model and costs 2653$. Berria MAKO BR LTD 2021 is the most expensive one and costs 8493$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2021 for 6370$. If we compare this with the average Crosscountry bike cost we notice that the price is 234.38% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This bike has the Fox Factory Float 34 fork installed. The fork’s travel is 110mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When leaving the production line, the MAKO BR 9 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Berria MAKO BR 9 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Berria MAKO BR 9 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
