Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 110mm -
Travel Rear 105mm -
Fork Fox Factory Float 34
-
Groupset GX Eagle AXS, X1 -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
153cm - 170cm
MD
168cm - 185cm
LG
183cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mako 3 BR, XCO Racing Geometry BGC, kinematic XCO WC 105mm, Full carbon UHM3X, Triple moncoque, Resin Matrix Nanotech CNT, full ball bearings ISB VMAX, BB92 botton bracket, Active Stay, Asymmetric, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2", Post Mounted brake PMS, 29"x2.35 maximun tire, BOOST Thru axle 148x12, Fox Live Valve ready, weight 1515g
Suspension Fork
FOX 34 SC Float Factory Air, Kashima FIT4, 15x110mm Kabolt, Axle 44mm offset, Tapered steerer, Reb. Adj. Lockout remote 3 Position, weight 1623g, 110mm travel
Rear Shock
FOX FACTORY FLOAT DPS BERRIA MAKO 3 WC XCO Tuning, EVOL SV 3 POS adjustment, Trunion 165X45mm, weight 244g, 105mm travel
Drivetrain
Rear Derailleur
SRAM GX AXS 12 Speed
Shift Levers
SRAM GX AXS EAGLE Controller
Cassette
SRAM XG1275, 10-52T
Crank
SRAM X1 DUB Eagle Boost 34T 170-175mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM GX Eagle CN-EAGL-GX-A1
Wheels
Rims
FULCRUM RED METAL 500, alloy, 27mm internal wide 1950g
Tires
Vittoria Barzo 2.25"X 29" / Tubeless ready /GRAPHENE 2.0 / 120 TPI
Brakes
Brakes
SRAM LEVEL TLM Disc 180/F 160/R
Cockpit
Handlebar
Avanforce Ltd, Intagrated handelbar Concept UD carbon Backsweep 9°, wide 740mm
Seat
Saddle
Fizik Taiga alloy rail
Seatpost
Advanceforce 0 offset, 31.6 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.442 mm | 1.366 mm | 1.299 mm |
| Bottom Bracket Height | 328 mm | 328 mm | 328 mm |
| Front Center | 680 mm | 708 mm | 742 mm |
| Rake | 45 mm | 40 mm | 40 mm |
| Trail | 98 mm | 103 mm | 103 mm |
| Stack | 598.6 mm | 607.9 mm | 617.2 mm |
| Reach | 415 mm | 445 mm | 475 mm |
| Top Tube Length | 571.9 mm | 605.6 mm | 656 mm |
| Seat Tube Angle | 74.2 ° | 74 ° | 73.7 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm |
| Head Tube Angle | 68.7 ° | 68.7 ° | 68.7 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1110 mm | 1139 mm | 1173 mm |
| Bottom Bracket Drop | 46 mm | 46 mm | 46 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 153 cm | 168 cm | 183 cm |
| Rider Max Height | 170 cm | 185 cm | 200 cm |
About this model
MAKO BR 9 completes the Berria Mako model. 64 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Berria MAKO 4 2022 is the most affordable bike of this model and has a price of 3503$. On the other hand, Berria MAKO BR LTD 2022, is the most expensive and costs 9343$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
MAKO BR 9 components
Fork
The Fox Factory Float 34 is included from the factory. It has a travel distance of 110mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is FOX FACTORY FLOAT DPS BERRIA MAKO 3 WC XCO Tuning, with a travel distance of 105mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
As for the wheels, Berria MAKO BR 9 2022, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Berria MAKO BR 9 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 153 cm – 200 cm (5.02 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
