Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 110mm -
Travel Rear 113mm -
Fork Fox Factory Float 34
-
Groupset XX SL Eagle Transmission -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mako 4 BR, XCO WC Racing Geometry BGC, 113mm travel with integrated IN-LINK suspension, Full carbon UHM2X, moncoque, resin HEXCEL HexPly, bearings full ball ISB VMAX, BB92 botton bracket, Full internal cable system ICS2, Integrated headset OH2S 1-1/2", Post Mounted brake PMS, 29"x2.40 maximun tyre, BOOST Thru axle 148x12, UDH standar, weight 1495g (without hardware).
Suspension Fork
FOX 34 SC Factory, Kashima Coat, FIT4 3P Lockout remote 3 Position, Float Evol Air, Reb. Adj. 15x110mm Kabolt axle, 44mm offset, Tapered steerer, weight 1623g, 110mm travel
Rear Shock
FOX Factory FLOAT DPS 3P Trunnion 165x45, Kashima Coat, Float Evol Air 3P Lockout remote 3 Position, weight 221g, 113mm travel
Drivetrain
Rear Derailleur
SRAM XX SL AXS T-TYPE, 12 Speed, weight 440g
Cassette
SRAM XG1299 Eagle T-TYPE, 10-52T, weight 372g
Crank
SRAM XX SL Q168, DUB, Direct mount 34T, T-TYPE 170-175mm, chain line 55mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM XX SL T-TYPE Flattop, weight 240g
Wheels
Rims
MAVIC CROSSMAX SL S, Aluminum S6000 rim, 25 mm internal wide, max. weight 150kg, weight 1610g
Tires
Vittoria Barzo 2.25"X 29", Tubeless Ready, GRAPHENE 2.0 120 TPI, weight 660g
Brakes
Brakes
SRAM LEVEL ULTIMATE STEALTH, tool free reach adjust, 2 pistons, 180/F and 160/R
Brake Levers
SRAM EC AXS POD ULTIMATE Controller
Cockpit
Handlebar
AGUILA BR, Integrated handlebar carbon Concept, wide 760mm, Backsweep 7°, Upsweep 5°, Rise 0mm, Stem lenght 60mm/75mm/95mm, weight 180gr
Seat
Saddle
Fizik Terra Aidon, Carbon Rail 7x10mm, width 145mm, length 255mm, weight 205g
Seatpost
TIBIA Flex Seat post, UD Carbon, 0 offset, 31,6 x 420mm, weight 220g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.356 mm | 1.314 mm | 1.266 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm |
| Front Center | 717 mm | 724 mm | 705 mm |
| Rake | 46 mm | 32 mm | -10 mm |
| Trail | 109 mm | 120 mm | 162 mm |
| Stack | 590 mm | 602 mm | 614 mm |
| Reach | 435 mm | 458 mm | 485 mm |
| Top Tube Length | 580 mm | 608 mm | 640 mm |
| Seat Tube Angle | 76.2 ° | 76 ° | 75.8 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm |
| Head Tube Angle | 67 ° | 67.5 ° | 68 ° |
| Head Tube Length | 85 mm | 95 mm | 105 mm |
| Chainstay Length | 430 mm | 445 mm | 490 mm |
| Wheelbase | 1143 mm | 1165 mm | 1191 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
MAKO BR LTD completes the Berria Mako model. There are 64 bikes that carry this model name. Check out the entire range from 2024 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
MAKO BR LTD components
Fork
The MAKO BR LTD comes factory-installed with the Fox Factory Float 34 fork. This has a travel range of 110mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Berria MAKO BR LTD bike has the FOX Factory FLOAT DPS 3P Trunnion 165×45 model installed, and has a travel of 113mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The MAKO BR LTD 2024 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The MAKO BR LTD comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
