Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 113mm -
Fork Fox Factory Float 34
-
Groupset X0 Eagle Transmission -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mako 4, XCO Geometry BGC, 113mm travel with integrated IN-LINK suspension, Full carbon HM2X, moncoque, resin HEXCEL HexPly, bearings full ball ISB VMAX, BB92 botton bracket, full internal cable system ICS2, Integrated headset OH2S 1-1/2", Post Mounted brake PMS, 29"x2.40 maximun tyre, BOOST Thru axle 148x12, UDH standar, weight 1795g (without hardware)
Suspension Fork
FOX 34 SC Factory, Kashima Coat, FIT4 3P Lockout remote 3 Position, Float Evol Air, Reb. Adj. 15x110mm Kabolt axle, 44mm offset, 1,5" Tapered steerer, weight 1738g, Shinny Black, 130mm travel
Rear Shock
FOX Factory FLOAT DPS 3P Trunnion 165x45, Kashima Coat, Float Evol Air 3P Lockout remote 3 Position, weight 221g, 113mm travel
Drivetrain
Rear Derailleur
SRAM X0 AXS Eagle T-TYPE, 12 Speed, weight 466g
Cassette
SRAM XG1295 Eagle T-TYPE, 10-52T
Crank
SRAM X0 Q174, DUB WIDE, 34T-TYPE 170-175mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM X0 T-TYPE Flattop, 256g
Wheels
Rims
MAVIC CROSSRIDE 30, 30 mm internal wide, max.weight 150kg, weight 2090g
Tires
Vittoria Barzo 2.35"X 29", Tubeless ready, GRAPHENE 2.0 120 TPI, weight 725g
Brakes
Brakes
SRAM LEVEL G2 RSC Disc tool free reach adjust, 4 Pistons, 200/F and 180/R 6T
Brake Levers
EC AXS POD right BRIDGE W/MMX
Cockpit
Handlebar
Avanforce AF1 TRAIL, UD carbon, 31,8mm, wide 780mm, Rise 25mm, Backsweep 7°, Upsweep 5°, weight 200g
Seat
Saddle
Fizik TERRA RIDON, Steel rails, width 255mm, width 145mm, weight 262g
Seatpost
FOX TRANSFER SL Ø31,6, Kashima Coat, 1X Lever, 125mm travel, 80-275mm min.-max. inserction, 455mm extended lenght, weight 432g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.379 mm | 1.336 mm | 1.285 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm |
| Front Center | 721 mm | 744 mm | 769 mm |
| Rake | 46 mm | 47 mm | 46 mm |
| Trail | 113 mm | 108 mm | 105 mm |
| Stack | 593 mm | 605 mm | 617 mm |
| Reach | 430 mm | 453 mm | 480 mm |
| Top Tube Length | 582 mm | 610 mm | 642 mm |
| Seat Tube Angle | 75.7 ° | 75.5 ° | 75.3 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm |
| Head Tube Angle | 66.5 ° | 67 ° | 67.5 ° |
| Head Tube Length | 85 mm | 95 mm | 105 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1147 mm | 1170 mm | 1195 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
MAKO DC 9 belongs to the Berria Mako model. There are 64 bikes that carry this model name. Check out the entire range from 2024 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This bike has the Fox Factory Float 34 fork installed. The fork’s travel is 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The MAKO DC 9 has a rear shock with a travel of 113mm. The model FOX Factory FLOAT DPS 3P Trunnion 165×45 is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The MAKO DC 9 2024 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Berria MAKO DC 9 comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
