Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 146mm -
Fork RockShox 35 Gold RL
-
Groupset NX Eagle, FSA -
Suspension Full -
Motor Polini 250W 90Nm mid-drive -
Battery PORTAPOWER 720Wh 36V 20Ah, Cells SAMSUNG INR21700-50E, 3960g -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mako Hybrid GT, Racing or Endurance adjustable Geometry BGC with Flip Chip System, Kinematic PERFORMANCE E-mtb 151-146mm, Full carbon HMR2X, Triple moncoque, Resin Matrix Nanotech CNT, bearings full ball ISB VMAX, Full internal cable system ICS2, Headset integrated OH2S 1-1/2" - 1-1.8", Post mounted system PMS brake, 29x2.60 maximun tyre, Thru axle Boost 12x148mm, weight 2600g
Suspension Fork
Rock Shox35 GOLD RL, Motion Control, 15x110mm Maxle Stealth, Tapered steerer OD 69, Rake 44mm, 35 mm straight wall STEEL Fast Black, weight 2377g, 150mm travel
Rear Shock
Rock Shox Deluxe BERRIA MAKO HYBRID Trail Custom, Solo Air, Trunion 185X55mm, 140mm travel
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12 Speed
Cassette
SRAM XG1210, 11-50T
Crank
FSA ISIS POLINI SYSTEM, aluminum, 34T, 165-170 mm
Chain
SRAM SX Eagle CN-EAGL-SX-A1
Wheels
Rims
FULCRUM E-METAL 700, alloy, TLR, 30mm internal width 2470g - 28(front) 28 (rear), Straight Pull Spokes 2,2-2 mm
Tires
FRONT Vittoria Martello 2.6"X 29", Tubeless ready, GRAPHENE 2.0 120 TPI, weight 1100g / REAR Vittoria Agarro 2.6"X 29", Tubeless ready, GRAPHENE 2.0, 120 TPI, weight 970g
Brakes
Brakes
SRAM DB8, 4 pistons, mineral oil, Disc 200/F 180/R
Brake Levers
SRAM SX Eagle Trigger
Cockpit
Stem
Avanforce ICS2 MTB, 0°, Ø31,8, 60-80mm
Handlebar
Avanforce 2, 31,8mm, wide 780mm
Seat
Saddle
ESSAX ERA, Steel rod, wide 145mm, length 250mm, weight 280g
Seatpost
TRANZX JD-YSPJL Aluminum 7075-T6, 0° offset, 31,6 x 421mm, 125mm travel
Motor & Battery
Motor
POLINI MX+ Tuning BR HYBRID Engine Control Unit, Shft Control Unit, Nominal performances 250W - 90Nm, Peak performances 600W, 144mm bottom bracket width, weight 2980g
Battery
PORTAPOWER 720Wh 36V 20Ah, Cells SAMSUNG INR21700-50E, 3960g
Charger
Porta Power charger 220-240V 3A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.39 mm | 1.31 mm |
| Front Center | 767 mm | 799 mm | 831 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 118 mm | 118 mm | 118 mm |
| Stack | 630.6 mm | 635.2 mm | 639.7 mm |
| Reach | 428 mm | 458 mm | 488 mm |
| Top Tube Length | 566.9 mm | 597 mm | 629.6 mm |
| Seat Tube Angle | 77.4 ° | 77.2 ° | 76.9 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm |
| Head Tube Angle | 64.8 ° | 64.8 ° | 64.8 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1213 mm | 1245 mm | 1278 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
MAKO HYBRID GT 6 completes the Berria E Mako model. There are 36 e-bikes that carry this model name. Take a sneak peek at all Berria E Mako e-bikes models from 2023, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Hybrid e-bikes
According to our math, the average price for a trustworthy Hybrid e-bike is 2480$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
This e-bike has the RockShox 35 Gold RL fork installed. The fork’s travel is 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
MAKO HYBRID GT 6 has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Rear Shock
As for the rear shock, this e-bike has the Rock Shox Deluxe BERRIA MAKO HYBRID Trail Custom model, with a travel of 146mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The MAKO HYBRID GT 6 2023 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The MAKO HYBRID GT 6 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Berria MAKO HYBRID GT 6 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Berria MAKO HYBRID GT 6 comes with a dropper post. Therefore, climbing or descending will be a breeze.
