Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 105mm -
Fork Fox Rhythm Float 32
-
Groupset NX Eagle, X1 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mako 3, XCO Racing Geometry BGC, kinematic XCO WC 105mm, Full carbon HMR2X, Triple moncoque, Resin Matrix Nanotech CNT, bearings full ball ISB VMAX, BB92 botton bracket, Active Stay, Asymmetric, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2", Post Mounted brake PMS, 29"x2.35 maximun tyre, BOOST Thru axle 148x12, Fox Live Valve ready, weight 1810g
Suspension Fork
FOX 32 Rhythm Air Grip, 15QRx110mm, Tapered steerer, Remote lockout, Reb. Adj.Rake 44mm, weight 1735g, 100mm travel
Rear Shock
FOX PERFORMANCE FLOAT DPS BERRIA MAKO 3 WC XCO Tuning, EVOL SV 3 POS adjustment, Trunion 165X45mm, weight 268g, 105mm travel
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12 Speed, weight 339g
Cassette
SRAM XG1210, 11-50T, weight 730g
Crank
SRAM X1 DUB Eagle Boost 34T 170-175mm
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM SX Eagle CN-EAGL-SX-A1
Wheels
Rims
FULCRUM RED ZONE 99, Alloy, internal width 23 mm, max. weight 120kg, weight 1850g
Tires
Vittoria Barzo 2.25"X 29", Tubeless Ready, GRAPHENE 2.0 120 TPI, weight 660g
Brakes
Brakes
SRAM LEVEL G2 R Disc, tool free reach adjust, 4 Pistons, 200/F and 180/R 6T
Brake Levers
SRAM NX Eagle, 12 Speed, weight 339g
Cockpit
Handlebar
Avanforce AF3, Aluminum 6061, 31, 8mm, wide 740mm, weight 330g
Seat
Saddle
Fizik Taiga alloy rail
Seatpost
Avanforce AF2, Aluminum 7075, 0mm offset, 31,6 x 400mm, weight 205g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.434 mm | 1.36 mm | 1.291 mm |
| Front Center | 681 mm | 714 mm | 748 mm |
| Rake | 54 mm | 53 mm | 53 mm |
| Trail | 75 mm | 76 mm | 76 mm |
| Stack | 595 mm | 605 mm | 613 mm |
| Reach | 415 mm | 445 mm | 475 mm |
| Top Tube Length | 577 mm | 615 mm | 652 mm |
| Seat Tube Angle | 74.7 ° | 74.3 ° | 74 ° |
| Seat Tube Length | 400 mm | 438 mm | 484 mm |
| Head Tube Angle | 69.2 ° | 69.2 ° | 69.2 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1114 mm | 1147 mm | 1181 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
MAKO SPORT is a Berria Mako model. 64 bikes variations carry this model name so far. You can get a glimpse at all models from 2024, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Fitness bikes
According to our math, the average price for a trustworthy Fitness bike is 656$. However, this doesn’t mean that if you spend less money on a Fitness bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The Fox Rhythm Float 32 is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is FOX PERFORMANCE FLOAT DPS BERRIA MAKO 3 WC XCO Tuning, with a travel distance of 105mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When leaving the production line, the MAKO SPORT model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Berria MAKO SPORT has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
