Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aero TT Disc ACR Carbon Monocoque
Suspension Fork
Aero TT, Integrated Tapered Full Carbon 1.5
Drivetrain
Rear Derailleur
Shimano 105 DI2 12sp
Front Derailleur
Shimano 105 DI2
Shift Levers
Shimano 105 DI2 Hydra
Cassette
Shimano 105 11/34
Crank
Shimano 105 52/36
Chain
Shimano 105
Wheels
Rims
Vision Team35
Tires
BH 700x28
Brakes
Brakes
Front: Shimano 105 hydraulic, Rear: Shimano 105 hydraulic
Cockpit
Stem
Aero TT ACR
Handlebar
Vision Trimax Carbon ACR
Headset
Aero TT ACR
Seat
Saddle
BH Ergo G
Seatpost
BH Aero TT
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.21 mm | 1.22 mm | 1.23 mm | 1.24 mm |
| Stack | 484.57 mm | 499.91 mm | 519.01 mm | 538.12 mm |
| Reach | 399.57 mm | 411.25 mm | 422.09 mm | 433.94 mm |
| Top Tube Length | 522 mm | 538 mm | 553 mm | 570 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 510 mm | 525 mm | 540 mm | 560 mm |
| Head Tube Angle | 72.5 ° | 72.8 ° | 72.8 ° | 72.8 ° |
| Head Tube Length | 185 mm | 100 mm | 120 mm | 140 mm |
| Chainstay Length | 371 mm | 371 mm | 371 mm | 371 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
AERO TT 4.0 is part of the Bh Aero model. There are 4 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the BH AERO TT 4.0 2023 has a starting price of 7905$. BH AERO TT 6.0 2023 on the other hand is the most expensive at 12771$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Triathlon bikes average price
According to our calculations, the average cost of a Triathlon bike that is reliable is 4177$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Triathlon bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 7905$. In conclusion, this bike price is 89.25% more expensive than the price of the average Triathlon bike.
AERO TT 4.0 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, BH AERO TT 4.0 2023, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AERO TT 4.0 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
