Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, Praxis -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery BH ATOMX, integrated, includes ILock with Smart Key bracelet -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon RL
Rear Shock
RockShox Deluxe, DebonAir spring
Drivetrain
Rear Derailleur
Shimano Deore M5100, 11-speed
Front Derailleur
None
Shift Levers
Shimano Deore M5100, 11-speed
Cassette
Shimano Deore M5100, 11-speed, 11-51 tooth
Crank
Praxis, 165mm length
Chain
Shimano HG60, 11-speed
Chain Guide
Upper slider
Pedals
None
Wheels
Front Hub
BH, HG driver
Rear Hub
BH, HG driver
Rims
Alexrims EXR30 TR
Spokes
Stainless steel
Tires
Front: Maxxis Minion DHF, EXO, TR, 60 TPI, 29" x 2.5", Rear: Maxxis Minion DHR II, EXO, TR, 60 TPI, 29" x 2.4"
Brakes
Brakes
Shimano MT420, 4-piston, 203mm rotors
Brake Levers
Shimano MT420
Cockpit
Stem
BH Ahead
Handlebar
BH MTB Riser, alloy, 780mm width
Grips
Ergon GE10
Headset
ACROS AIX-322 OD46
Seat
Saddle
Prologo Proxim W350 STN
Seatpost
KS Rage-i dropper
Motor & Battery
Motor
Brose S-Mag, 90Nm max torque
Battery
BH ATOMX, integrated, includes ILock with Smart Key bracelet
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.48 mm | 1.41 mm | 1.42 mm |
| Stack | 621 mm | 621 mm | 626 mm | 645 mm |
| Reach | 409 mm | 421 mm | 444 mm | 454 mm |
| Top Tube Length | 584 mm | 596 mm | 620 mm | 637 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.3 ° |
| Seat Tube Length | 425 mm | 450 mm | 485 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 115 mm | 115 mm | 120 mm | 140 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
ATOMX Lynx 5.5 Pro-L belongs to the Bh E Atomx model. 58 e-bikes variations carry this model name so far. Take a sneak peek at all Bh E Atomx e-bikes models from 2021, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
ATOMX Lynx 5.5 Pro-L components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
BH ATOMX Lynx 5.5 Pro-L e-bike has the RockShox Deluxe model installed, and has a travel of 140mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, BH ATOMX Lynx 5.5 Pro-L 2021, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
BH ATOMX Lynx 5.5 Pro-L e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the ATOMX Lynx 5.5 Pro-L. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
