Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork Fox Factory Float 36
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery ATOMX, integrated -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX FLOAT 36 Factory, GRIP2 damper
Rear Shock
FOX FLOAT DPX2 Performance
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM Eagle, 12-speed, 11-50 tooth
Crank
SRAM
Chain
SRAM NX Eagle, 12-speed
Chain Guide
Upper slider
Pedals
N/A
Wheels
Front Hub
BH, HG driver
Rear Hub
BH, HG driver
Rims
Alexrims Volar 3.8 TR
Spokes
Stainless steel
Tires
Schwalbe Magic Mary, TR, 27.5" x 2.8"
Brakes
Brakes
Shimano Deore XT, 2-piston, 200mm rotors
Brake Levers
Shimano Deore XT
Cockpit
Stem
BH A-Head
Handlebar
BH MTB Light Riser, alloy, 780mm width
Grips
Ergon GE10 Factory
Headset
Tapered
Seat
Saddle
fi'zi:k Taiga
Seatpost
KS Eten-I dropper
Motor & Battery
Motor
Brose S Mag, 90Nm max torque
Battery
ATOMX, integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.37 mm | 1.38 mm |
| Stack | 610 mm | 607 mm | 628 mm |
| Reach | 423 mm | 444 mm | 454 mm |
| Top Tube Length | 591 mm | 610 mm | 628 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 120 mm | 120 mm | 114 mm |
| Chainstay Length | 464 mm | 464 mm | 464 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
ATOMX Lynx 6 Pro-SE 27.5+ belongs to the Bh E Atomx model. 58 e-bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro e-bikes average price
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The Fox Factory Float 36 is included from the factory. It has a travel distance of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the FOX FLOAT DPX2 Performance rear shock model, which has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The ATOMX Lynx 6 Pro-SE 27.5+ 2020 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The ATOMX Lynx 6 Pro-SE 27.5+ has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The BH model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
