Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork Suntour RAIDON
-
Groupset Deore, Shimano -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Expert Alu 29", 148x12, integrated headset 42ACB
Suspension Fork
SR Suntour Raidon RLR Remote Lock 100mm
Drivetrain
Rear Derailleur
Shimano Deore 6100 12sp
Shift Levers
Shimano Deore 6100 12sp
Cassette
Shimano Deore 6100 10/51
Crank
Shimano MT510, 175mm
Bottom Bracket
Shimano
Chain
Shimano Deore
Wheels
Rims
BH Lite
Tires
Continental Cross King 2.20/ Maxxis Ikon 2.20
Brakes
Brakes
Shimano MT201 180mm
Cockpit
Stem
BH SL 80mm, 31,8mm, +/-6º
Handlebar
BH Lite flat 780mm
Grips
BH Lock On
Headset
BH SL integrated sealed bearing
Seat
Saddle
BH
Seatpost
BH Lite 31,6mm, 420mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.559 mm | 1.463 mm | 1.444 mm | 1.419 mm |
| Stack | 619 mm | 619 mm | 628 mm | 647 mm |
| Reach | 397 mm | 423 mm | 435 mm | 456 mm |
| Top Tube Length | 580 mm | 607 mm | 622 mm | 648 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1091 mm | 1121 mm | 1136 mm | 1164 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
EXPERT 4.0 completes the Bh Expert model. BH launched 42 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
BH EXPERT JUNIOR 14″ 2022 is the cheapest bike model and costs 412$. BH EXPERT 5.5 2022 is the most expensive one and costs 2006$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When BH released this model in 2022, its price was 1252$. If we compare this with the average Crosscountry bike cost we notice that the price is 52.16% smaller.
EXPERT 4.0 components
Fork
The Suntour RAIDON is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the EXPERT 4.0 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The EXPERT 4.0 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
