Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset GRX 800, 105 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Gravel X Alloy 7005 Hydroforming
Suspension Fork
Gravel X Carbon 1.5
Drivetrain
Rear Derailleur
Shimano GRX 810 11sp
Shift Levers
Shimano 105 hydra
Cassette
Shimano SLX 11/42
Crank
FSA Vero Pro Mono 40T
Chain
FSA TH-CN1102
Wheels
Rims
Shimano RS171 Disc
Tires
Hutchinson Overide 700x38
Brakes
Brakes
Shimano Disc hydra
Cockpit
Stem
BH SL
Handlebar
BH Lite Gravel
Headset
BH SL integrated sealed bearing
Seat
Saddle
San Marco Monza Start
Seatpost
BH Lite 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.49 mm | 1.51 mm |
| Stack | 509.5 mm | 538.7 mm | 567.7 mm | 596.1 mm |
| Reach | 358 mm | 369.9 mm | 382 mm | 394.1 mm |
| Top Tube Length | 521 mm | 542 mm | 563 mm | 584 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 71.1 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 100 mm | 125 mm | 150 mm | 180 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
GRAVELX ALU 2.0 is a Bh Gravelx model. There are 18 bikes that carry this model name. You can easily view all of the Bh Gravelx bikes models from 2022, here.
Model range prices
BH GRAVELX ALU 1.0 2022 is the most economical model, with a starting price of 2006$. BH GRAVELX EVO 4.5 2022 on the other hand costs 7054$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When BH released this model in 2022, its price was 2371$. In conclusion, this bike price is 3.84% lower than the price of the average Gravel bike.
GRAVELX ALU 2.0 components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The GRAVELX ALU 2.0 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
GRAVELX ALU 2.0 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
