Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Gravel X Carbon Monocoque
Suspension Fork
Gravel X Evo Carbon 1.5
Drivetrain
Rear Derailleur
Shimano GRX 810 11sp
Shift Levers
Shimano GRX 810 hydra
Cassette
Shimano SLX 11/42
Crank
FSA Omega Mono 40T, X, Crank set, FSA Omega Mono 40T
Chain
FSA TH-CN1102
Wheels
Rims
Shimano RS171 Disc
Tires
Hutchinson Touareg Tan 700x40
Brakes
Brakes
Front: Shimano GRX hydra, Rear: Shimano GRX hydra
Cockpit
Stem
BH SL, X, Stem, BH SL
Handlebar
BH Lite Gravel, X, Handlebar, BH Lite Gravel
Headset
BH SL integrated sealed bearing
Seat
Saddle
BH Ergo G
Seatpost
BH Lite Gravel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.42 mm | 1.46 mm | 1.49 mm | 1.51 mm |
| Stack | 509.5 mm | 509.5 mm | 538.7 mm | 567.7 mm | 596.1 mm |
| Reach | 358 mm | 358 mm | 369.9 mm | 382 mm | 394.1 mm |
| Top Tube Length | 521 mm | 521 mm | 542 mm | 563 mm | 584 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 460 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 71.1 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 100 mm | 100 mm | 125 mm | 150 mm | 180 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
GRAVELX EVO 3.0 belongs to the Bh Gravelx model. 18 bikes variations carry this model name so far. Take a sneak peek at all Bh Gravelx bikes models from 2023, by clicking here.
Model range prices
BH GRAVELX ALU 1.0 2023 is the cheapest bike model and costs 2188$. BH GRAVELX 4.5 2023 is the most expensive one and costs 7662$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When BH released this model in 2023, its price was 3526$. Comparing the average cost of a Gravel bike to this one, you will see that GRAVELX EVO 3.0 price is 43.22% more expensive.
Overview of components
Fork material
GRAVELX EVO 3.0 has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When leaving the production line, the GRAVELX EVO 3.0 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The GRAVELX EVO 3.0 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
BH GRAVELX EVO 3.0 bike has 5 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
