Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Gravel X Carbon Monocoque
Suspension Fork
Gravel X Evo Carbon 1.5
Drivetrain
Rear Derailleur
Shimano GRX 810 11sp
Front Derailleur
Shimano GRX 810
Shift Levers
Shimano GRX 810 hydra
Cassette
Shimano 105 11/34
Crank
Shimano GRX 46/30, X, Crank set, Shimano GRX 46/30
Chain
FSA TH-CN1102
Wheels
Rims
Shimano RS171 Disc
Tires
Hutchinson Touareg Tan 700x40
Brakes
Brakes
Front: Shimano GRX hydra, Rear: Shimano GRX hydra
Cockpit
Stem
BH SL, X, Stem, BH SL
Handlebar
BH Lite Gravel, X, Handlebar, BH Lite Gravel
Headset
BH SL integrated sealed bearing
Seat
Saddle
Prologo AGX
Seatpost
BH Lite Gravel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.42 mm | 1.46 mm | 1.49 mm | 1.51 mm |
| Stack | 509.5 mm | 509.5 mm | 538.7 mm | 567.7 mm | 596.1 mm |
| Reach | 358 mm | 358 mm | 369.9 mm | 382 mm | 394.1 mm |
| Top Tube Length | 521 mm | 521 mm | 542 mm | 563 mm | 584 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 460 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 71.1 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 100 mm | 100 mm | 125 mm | 150 mm | 180 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
GRAVELX EVO 3.5 belongs to the Bh Gravelx model. BH launched 18 bikes of this model so far. Take a sneak peek at all Bh Gravelx bikes models from 2023, by clicking here.
Model range prices
BH GRAVELX ALU 1.0 2023 is the most economical model, with a starting price of 2188$. BH GRAVELX 4.5 2023 on the other hand costs 7662$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, BH GRAVELX EVO 3.5 price was 3770$. In conclusion, this bike price is 53.13% higher than the price of the average Gravel bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The GRAVELX EVO 3.5 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The GRAVELX EVO 3.5 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
BH GRAVELX EVO 3.5 bike has 5 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
