Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX Di2, FSA -
Suspension Rigid -
Drivetrain Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Gravel X Carbon Monocoque
Suspension Fork
Gravel X Evo Carbon 1.5
Drivetrain
Rear Derailleur
Shimano GRX DI2
Shift Levers
Shimano GRX DI2
Cassette
Shimano SLX 11/42
Crank
FSA Omega Mono 40T
Chain
FSA TH-CN1102
Wheels
Rims
Vision Team TC30 Disc
Tires
Hutchinson Touareg Tan 700x40
Brakes
Brakes
Shimano GRX hydra
Cockpit
Stem
BH SL
Handlebar
BH Lite Gravel
Headset
BH SL integrated sealed bearing
Seat
Saddle
Prologo AGX
Seatpost
BH Lite Gravel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.49 mm | 1.51 mm |
| Stack | 509.5 mm | 538.7 mm | 567.7 mm | 596.1 mm |
| Reach | 358 mm | 369.9 mm | 382 mm | 394.1 mm |
| Top Tube Length | 521 mm | 542 mm | 563 mm | 584 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 71.1 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 100 mm | 125 mm | 150 mm | 180 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
GRAVELX EVO 4.0 belongs to the Bh Gravelx model. 18 bikes variations carry this model name so far. Take a sneak peek at all Bh Gravelx bikes models from 2022, by clicking here.
Model range prices
The most economical model, the BH GRAVELX ALU 1.0 2022 has a starting price of 2006$. BH GRAVELX EVO 4.5 2022 on the other hand is the most expensive at 7054$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2022 and its price was 4864$. Doing a quick comparison, we notice that GRAVELX EVO 4.0 price is 97.56% more expensive than the average cost of a Gravel bike.
GRAVELX EVO 4.0 components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on GRAVELX EVO 4.0 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The GRAVELX EVO 4.0 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
