Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset XT, FSA -
Suspension Full -
Motor 250W 65Nm mid-drive -
Battery BH, integrated -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 34 Performance
Rear Shock
FOX FLOAT DPS Performance
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
None
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth
Crank
FSA, 165mm length
Chain
Shimano Deore M6100, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
BH Evo, MICRO SPLINE driver
Rear Hub
BH Evo, MICRO SPLINE driver
Rims
BH Evo A30 TR, 28 hole
Spokes
Stainless steel
Tires
Front: Maxxis Ardent, 3C MaxxSpeed, EXO, TR, 120 TPI, 29" x 2.35", Rear: Maxxis Ikon, 3C MaxxSpeed, EXO, TR, 120 TPI, 29" x 2.35"
Brakes
Brakes
Shimano Deore XT M8120, 4-piston, 203mm rotors
Brake Levers
Shimano Deore XT M8120
Cockpit
Stem
BH SLite Ahead
Handlebar
BH MTB SLite Riser, alloy, 780mm width
Grips
Ergon GE1 Factory
Headset
ACROS AIF-546 ICR Block Lock
Seat
Saddle
Prologo Scratch M5 STN
Seatpost
BikeYoke Divine dropper
Motor & Battery
Motor
BH 2ESMAG, 250W, 65 Nm max torque
Battery
BH, integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.451 mm | 1.404 mm | 1.357 mm |
| Stack | 598 mm | 605 mm | 612 mm |
| Reach | 412 mm | 431 mm | 451 mm |
| Top Tube Length | 573 mm | 595 mm | 615 mm |
| Seat Tube Angle | 74.7 ° | 74.7 ° | 74.7 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm |
| Head Tube Angle | 67.7 ° | 67.7 ° | 67.7 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
iLynx Race Carbon 8.2 LT is part of the Bh E Ilynx model. There are 30 e-bikes that carry this model name. Check out the entire range from 2021 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
iLynx Race Carbon 8.2 LT components
Fork
The fork installed on this bike is the Fox Performance Float 34 model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The iLynx Race Carbon 8.2 LT has a rear shock with a travel of 120mm. The model FOX FLOAT DPS Performance is the one installed in this e-bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The iLynx Race Carbon 8.2 LT 2021 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. BH iLynx Race Carbon 8.2 LT is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
iLynx Race Carbon 8.2 LT comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the iLynx Race Carbon 8.2 LT. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
