Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XT, FSA -
Suspension Full -
Motor 250W 65Nm mid-drive -
Battery BH, integrated, plus XPro external battery -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 34 Factory
Rear Shock
FOX FLOAT DPS Performance
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
None
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth
Crank
FSA, 165mm length
Chain
Shimano Deore M6100, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
BH Evo, MICRO SPLINE driver
Rear Hub
BH Evo, MICRO SPLINE driver
Rims
BH Evo C30 Carbon TR
Spokes
Stainless steel
Tires
Front: Maxxis Ardent, 3C MaxxSpeed, EXO, TR, 120 TPI, 29" x 2.35", Rear: Maxxis Ikon, 3C MaxxSpeed, EXO, TR, 120 TPI, 29" x 2.35"
Brakes
Brakes
Shimano Deore XT M8120, 4-piston, 203mm rotors
Brake Levers
Shimano Deore XT M8120
Cockpit
Stem
BH SLite Ahead
Handlebar
BH Evo Carbon Riser, alloy, 760mm width
Grips
Ergon GE1 Factory
Headset
ACROS AIF-546 ICR Block Lock
Seat
Saddle
Prologo Scratch M5 STN
Seatpost
BikeYoke Divine dropper
Motor & Battery
Motor
BH 2ESMAG, 250W, 65 Nm max torque
Battery
BH, integrated, plus XPro external battery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.451 mm | 1.404 mm | 1.357 mm |
| Stack | 598 mm | 605 mm | 612 mm |
| Reach | 412 mm | 431 mm | 451 mm |
| Top Tube Length | 573 mm | 595 mm | 615 mm |
| Seat Tube Angle | 74.7 ° | 74.7 ° | 74.7 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm |
| Head Tube Angle | 67.7 ° | 67.7 ° | 67.7 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
iLynx Race Carbon 8.4 LT Pro is part of the Bh E Ilynx model. 30 e-bikes variations carry this model name so far. Take a sneak peek at all Bh E Ilynx e-bikes models from 2021, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail e-bikes
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The Fox Factory Float 34 is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
BH iLynx Race Carbon 8.4 LT Pro e-bike has the FOX FLOAT DPS Performance model installed, and has a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The iLynx Race Carbon 8.4 LT Pro 2021 e-bike is equipped with 29″ carbon wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The iLynx Race Carbon 8.4 LT Pro comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
iLynx Race Carbon 8.4 LT Pro comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
