Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox Rhythm Float 34
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX FLOAT 34 Rhythm, GRIP damper
Rear Shock
FOX FLOAT DPS Performance, EVOL, 184mm x 44mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
None
Shift Levers
Shimano Deore M6100, 12-speed
Cassette
Shimano Deore M6100, 12-speed, 10-51 tooth
Crank
Shimano MT510, 175mm length
Bottom Bracket
Shimano
Chain
Shimano Deore M6100, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
BH SL T30 wheelset, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rear Hub
BH SL T30 wheelset, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rims
BH SL T30 wheelset, 30mm width, 32 hole, tubeless
Spokes
BH SL T30 wheelset
Tires
Michelin Wild Enduro, Magi-X front, Gum-X rear, 29" x 2.4"
Brakes
Brakes
Shimano M6000, 2-piston, 180mm rotors
Brake Levers
Shimano M6000
Cockpit
Stem
BH SL, 60mm length, 31.8mm bar clamp, 6° rise
Handlebar
BH Lite Rizer, 780mm width, 31.8mm clamp diameter
Grips
BH SL, lock-on
Headset
BH SL, integrated, sealed bearings
Seat
Saddle
Prologo Scratch X8
Seatpost
BH Lite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.414 mm | 1.377 mm | 1.352 mm | 1.325 mm |
| Stack | 601 mm | 606 mm | 615 mm | 624 mm |
| Reach | 425 mm | 440 mm | 455 mm | 471 mm |
| Top Tube Length | 583 mm | 597 mm | 616 mm | 635 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1160 mm | 1175 mm | 1194 mm | 1214 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Lynx 5 Alu 5.0 completes the Bh Lynx model. BH released 77 bikes variations of this model so far. You can easily view all of the Bh Lynx bikes models from 2021, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Lynx 5 Alu 5.0 components
Fork
BH Lynx 5 Alu 5.0 2021 bike is equipped with the Fox Rhythm Float 34 fork, and has 130mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The Lynx 5 Alu 5.0 has a rear shock with a travel of 130mm. The model FOX FLOAT DPS Performance is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Lynx 5 Alu 5.0 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Lynx 5 Alu 5.0 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
