Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox Rhythm Float 34
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 34 Rhythm, GRIP damper
Rear Shock
FOX FLOAT DPS Performance
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM NX Eagle, 12-speed, 11-50 tooth
Crank
SRAM NX Eagle, 175mm length
Bottom Bracket
SRAM, 92mm PressFit
Chain
SRAM NX Eagle, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
BH SL TLR30 wheelset, 32 hole, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
BH SL TLR30 wheelset, 32 hole, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
BH SL TLR30 wheelset, 30mm width, 32 hole, tubeless
Spokes
BH SL TLR30 wheelset
Tires
Front: Michelin Wild AM, 29" x 2.3", Rear: Michelin Force AM, 29" x 2.3"
Brakes
Brakes
Shimano M6000, 2-piston, 180mm rotors
Brake Levers
Shimano M6000
Cockpit
Stem
BH SL, 60mm length, 31.8mm bar clamp, 6° rise
Handlebar
BH Lite Rizer, 780mm width, 31.8mm clamp diameter, 20mm rise, 4° upsweep, 6° backsweep
Grips
BH, lock-on
Headset
BH SL, integrated, sealed bearings
Seat
Saddle
Prologo Kappa RS
Seatpost
KS Eten-I dropper, 125mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.414 mm | 1.377 mm | 1.352 mm | 1.325 mm |
| Stack | 601 mm | 606 mm | 615 mm | 624 mm |
| Reach | 425 mm | 440 mm | 455 mm | 471 mm |
| Top Tube Length | 583 mm | 597 mm | 616 mm | 635 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1160 mm | 1175 mm | 1194 mm | 1214 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Lynx 5 Carbon 6.9 completes the Bh Lynx model. BH released 77 bikes variations of this model so far. You can easily view all of the Bh Lynx bikes models from 2020, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the Fox Rhythm Float 34 model. The travel on this model is 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
BH Lynx 5 Carbon 6.9 bike has the FOX FLOAT DPS Performance model installed, and has a travel of 130mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The Lynx 5 Carbon 6.9 2020 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. BH Lynx 5 Carbon 6.9 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The BH model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
