Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox Performance Float 32
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 32 Step-Cast (SC) Performance, remote lockout
Rear Shock
FOX FLOAT DPS Factory, EVOL air can, Kashima coating, remote lockout
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
N/A
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth
Crank
Shimano Deore XT M8100, 175mm length
Bottom Bracket
Shimano, 92mm PressFit
Chain
Shimano Deore XT, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
BH Evo wheelset, 28 hole, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rear Hub
BH Evo wheelset, 28 hole, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rims
BH Evo wheelset, alloy, 25mm width, 28 hole, tubeless
Spokes
BH Evo wheelset
Tires
Front: Maxxis Ardent Race, 3C MaxxSpeed, EXO, 29" x 2.2", Rear: Maxxis Ikon, 3C MaxxSpeed, EXO, 29" x 2.2"
Brakes
Brakes
Shimano Deore XT, 2-piston, 180mm front rotor, 160mm rear rotor
Brake Levers
Shimano Deore XT
Cockpit
Stem
BH Evo, 80mm length, 31.8mm bar clamp, 6° drop
Handlebar
BH Evo Carbon Midflat, 760mm width, 31.8mm clamp diameter, 8mm rise, 5° upsweep, 7° backsweep
Grips
BH Control, lock-on
Headset
BH Evo
Seat
Saddle
Prologo Dimension
Seatpost
BH Evo Carbon, 420mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.41 mm | 1.38 mm | 1.36 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 674 mm | 702 mm | 727 mm | 750 mm |
| Rake | 56 mm | 56 mm | 56 mm | 55 mm |
| Trail | 87 mm | 87 mm | 87 mm | 88 mm |
| Stack | 578 mm | 587 mm | 601 mm | 615 mm |
| Reach | 391 mm | 416 mm | 435 mm | 453 mm |
| Top Tube Length | 564 mm | 592 mm | 615 mm | 637 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 410 mm | 440 mm | 480 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1089 mm | 1117 mm | 1142 mm | 1165 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Lynx Race Evo Carbon 8.5 is a Bh Lynx model. BH launched 77 bikes of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Lynx Race Evo Carbon 8.5 components
Fork
The fork installed on this bike is the Fox Performance Float 32 model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
BH Lynx Race Evo Carbon 8.5 bike has the FOX FLOAT DPS Factory model installed, and has a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Lynx Race Evo Carbon 8.5 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Lynx Race Evo Carbon 8.5 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
BH Lynx Race Evo Carbon 8.5 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
