Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 34 Step-Cast (SC) Factory, Kashima coating, remote lockout
Rear Shock
FOX FLOAT DPS Factory, EVOL, Kashima coating, remote lockout, 190mm x 45mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
None
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth
Crank
Shimano Deore XT M8100, 175mm length
Bottom Bracket
Shimano
Chain
Shimano Deore XT M8100, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
BH EVO wheelset, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rear Hub
BH EVO wheelset, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rims
BH EVO wheelset, alloy, 25mm width, 28 hole, tubeless
Spokes
BH EVO wheelset
Tires
Front: Maxxis Ardent Race, EXO, 29" x 2.2", Rear: Maxxis Ikon, EXO, 29" x 2.2"
Brakes
Brakes
Shimano Deore XT, 2-piston, 180mm front rotor, 160mm rear rotor
Brake Levers
Shimano Deore XT
Cockpit
Stem
BH LYNX Race EVO, 60mm length, 0° drop, 31.8mm bar clamp
Handlebar
BH EVO Carbon Midflat, 760mm width, 8mm rise, 5° upsweep, 7° backsweep, 31.8mm clamp diameter
Grips
BH Control, lock-on
Headset
ACROS Lynx Race EVO, stainless steel bearings, BlockLock system limits rotation to 150°
Seat
Saddle
Prologo Scratch M5
Seatpost
BikeYoke Divine SL dropper, 80mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.457 mm | 1.36 mm | 1.333 mm | 1.32 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 668 mm | 706 mm | 727 mm | 744 mm |
| Rake | 40 mm | 44 mm | 39 mm | 34 mm |
| Trail | 112 mm | 107 mm | 113 mm | 118 mm |
| Stack | 580 mm | 585 mm | 600 mm | 615 mm |
| Reach | 398 mm | 430 mm | 450 mm | 466 mm |
| Top Tube Length | 568 mm | 578 mm | 599 mm | 619 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 75 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 95 mm | 110 mm | 140 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1096 mm | 1134 mm | 1155 mm | 1172 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Lynx Race EVO Carbon 9.0 LT belongs to the Bh Lynx model. There are 77 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The Fox Factory Float 34 is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Lynx Race EVO Carbon 9.0 LT has a rear shock with a travel of 120mm. The model FOX FLOAT DPS Factory is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Lynx Race EVO Carbon 9.0 LT model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Lynx Race EVO Carbon 9.0 LT comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
BH Lynx Race EVO Carbon 9.0 LT includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
