Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RS1 Disc ACR Monocoque
Suspension Fork
RS1 Disc Full Integrated Tapeder, Full Carbon 1.5
Drivetrain
Rear Derailleur
Shimano Ultegra DI2 12sp
Front Derailleur
Shimano Ultegra DI2
Shift Levers
Shimano Ultegra DI2 Hydra
Cassette
Shimano Ultegra 11/34
Crank
Shimano Ultegra 52/36 12v
Chain
Shimano Ultegra 12v
Wheels
Rims
Vision Team35
Tires
Hutchinson Nitro2 700x 28
Brakes
Brakes
Shimano Ultegra hydraulic
Cockpit
Stem
EVO Monocoque ACR
Handlebar
EVO Monocoque ACR
Headset
FSA ACR
Seat
Saddle
Prologo Nago RS
Seatpost
RS1 Aero
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.48 mm | 1.51 mm | 1.53 mm |
| Stack | 518 mm | 536 mm | 549 mm | 575 mm | 589 mm |
| Reach | 362 mm | 367 mm | 372 mm | 380 mm | 385 mm |
| Top Tube Length | 508 mm | 523 mm | 537 mm | 553 mm | 568 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm |
| Head Tube Angle | 71 ° | 72 ° | 72.5 ° | 73 ° | 73.5 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 175 mm | 190 mm |
| Chainstay Length | 404 mm | 404 mm | 407 mm | 407 mm | 410 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
RS1 4.5 is a Bh Rs1 model. BH launched 10 bikes of this model so far. Take a sneak peek at all Bh Rs1 bikes models from 2022, by clicking here.
Model range prices
BH RS1 3.0 2022 is the most economical model, with a starting price of 3526$. BH RS1 5.0 2022 on the other hand costs 7054$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When BH released this model in 2022, its price was 6081$. Comparing the average cost of a Race bike to this one, you will see that RS1 4.5 price is 81.52% higher.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The RS1 4.5 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The RS1 4.5 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
