Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Groupset Tourney, Shimano -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spike 29", Alloy Frame
Suspension Fork
Spike
Drivetrain
Rear Derailleur
Shimano TX55 7sp
Front Derailleur
Shimano TY300
Shift Levers
Shimano ST-EF505
Cassette
Shimano HG-200
Crank
Prowheel
Bottom Bracket
Integrated
Chain
KMC
Pedals
Fasten
Wheels
Front Hub
Shimano TX505
Rear Hub
Shimano TX505
Rims
Alloy 29"
Tires
DSI
Brakes
Brakes
Front: Shimano MT-200, Rear: Shimano MT-200
Cockpit
Stem
BH Alloy
Handlebar
BH
Grips
BH
Headset
BH
Seat
Saddle
BH
Seatpost
BH
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 649 mm | 662 mm | 676 mm | 696 mm |
| Top Tube Length | 582 mm | 594 mm | 607 mm | 627 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1104 mm | 1117 mm | 1131 mm | 1151 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
SPIKE 1.0 completes the Bh Spike model. BH released 8 bikes variations of this model so far. Take a sneak peek at all Bh Spike bikes models from 2023, by clicking here.
Model range prices
BH SPIKE 2.0 2023 is the most affordable bike of this model and has a price of 716$. On the other hand, BH SPIKE 3.0 2023, is the most expensive and costs 1069$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 716$. Comparing this to the average Trail bike price, we see that the price is 285.75% lower.
Overview of components
Wheels size
When it comes to wheels, the SPIKE 1.0 bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The SPIKE 1.0 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
