Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork Suntour RAIDON
-
Groupset 105, Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spike Alu 29", 135x9mm, integrated headset 42ACB
Suspension Fork
SR Suntour Raidon RLR Remote Lock 100mm
Drivetrain
Rear Derailleur
Shimano Deore 5100 11sp
Shift Levers
Shimano Deore 5100 11sp
Cassette
Shimano Deore M5100 11/51
Crank
Shimano M5100 30, 175mm
Bottom Bracket
Shimano
Chain
FSA Team Issue 11sp
Pedals
WELLGO
Wheels
Rims
BH, Shimano TX505 32H
Tires
Mitas Ocelot 2.35
Brakes
Brakes
Shimano MT200 180mm
Cockpit
Stem
BH 90mm
Handlebar
BH
Grips
BH Lock On
Headset
BH sealed bearing
Seat
Saddle
BH
Seatpost
BH
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.57 mm | 1.55 mm | 1.47 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 649 mm | 662 mm | 676 mm | 696 mm |
| Rake | 38 mm | 38 mm | 38 mm | 25 mm |
| Trail | 107 mm | 107 mm | 107 mm | 121 mm |
| Stack | 621 mm | 631 mm | 641 mm | 651 mm |
| Reach | 394 mm | 403 mm | 413 mm | 443 mm |
| Top Tube Length | 582 mm | 594 mm | 607 mm | 627 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1104 mm | 1117 mm | 1131 mm | 1151 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
SPIKE 3.0 is part of the Bh Spike model. BH released 8 bikes variations of this model so far. Take a sneak peek at all Bh Spike bikes models from 2022, by clicking here.
Model range prices
BH SPIKE 2.0 2022 is the most affordable bike of this model and has a price of 716$. On the other hand, BH SPIKE 3.0 2022, is the most expensive and costs 1069$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2022 for 1069$. Comparing the average cost of a Crosscountry bike to this one, you will see that SPIKE 3.0 price is 78.2% smaller.
SPIKE 3.0 components
Fork
The Suntour RAIDON is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the SPIKE 3.0 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. BH SPIKE 3.0 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
BH SPIKE 3.0 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
