Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Factory Float 34
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ultimate EVO Carbon, EC Layup, Acros ICR, PF92BB, 148x12,UDH
Suspension Fork
Fox 34SC Factory Push to Lock Kabolt 100mm
Drivetrain
Rear Derailleur
Shimano XT 8100 12sp
Shift Levers
Shimano XT 8100 12sp
Cassette
Shimano XT 8100 10/51
Crank
Shimano XT 8100 34, 175mm
Bottom Bracket
Shimano
Chain
Shimano XT
Wheels
Front Hub
Shimano MT400/410
Rear Hub
Shimano MT400/410
Rims
Race Face Aeffect TLR, 27mm, 32H
Spokes
Inox 2.0
Tires
Maxxis Ardent EXO 2.25 Front/ Maxxis Ikon EXO 2.25 rear
Brakes
Brakes
Shimano XT 180mm
Cockpit
Stem
BH FIT 60mm, 31,8mm, -6º
Handlebar
BH SL Top Flat 780mm, 10mm Rise
Grips
BH Control Grip
Headset
Acros ICR FIT 36/45º, Block Lock 160º
Seat
Saddle
Prologo Scratch M5
Seatpost
BH SL 31,6mm 420mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.504 mm | 1.437 mm | 1.393 mm | 1.402 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 682 mm | 703 mm | 733 mm | 754 mm |
| Rake | 59 mm | 51 mm | 53 mm | 49 mm |
| Trail | 84 mm | 96 mm | 94 mm | 98 mm |
| Stack | 605.5 mm | 610.1 mm | 624.1 mm | 648.5 mm |
| Reach | 402.5 mm | 424.5 mm | 448 mm | 462.5 mm |
| Top Tube Length | 580 mm | 595.5 mm | 629.4 mm | 648.5 mm |
| Seat Tube Angle | 74.2 ° | 74 ° | 74 ° | 73.8 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 545 mm |
| Head Tube Angle | 68.5 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1093 mm | 1114 mm | 1145 mm | 1165 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
ULTIMATE EVO 8.5 is part of the Bh Ultimate model. BH released 45 bikes variations of this model so far. You can easily view all of the Bh Ultimate bikes models from 2022, here.
Model range prices
The most economical model, the BH ULTIMATE RC 6.5 2022 has a starting price of 2249$. BH ULTIMATE EVO 9.9 2022 on the other hand is the most expensive at 9000$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2022 for 4986$. Comparing this to the average Crosscountry bike price, we see that the price is 161.73% more expensive.
ULTIMATE EVO 8.5 components
Fork
The fork installed on this bike is the Fox Factory Float 34 model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, BH ULTIMATE EVO 8.5 2022, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
