Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Factory Float 34
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ultimate EVO Carbon, EC Layup, Acros ICR, PF92BB, 148x12,UDH
Suspension Fork
Fox 34SC Factory Push to Lock Kabolt 100mm
Drivetrain
Rear Derailleur
Shimano XT 8100 12sp
Shift Levers
Shimano XT 8100 12sp
Cassette
Shimano XT 8100 10/51
Crank
Shimano XT 8100 34, 175mm
Bottom Bracket
Shimano
Chain
Shimano XT
Wheels
Front Hub
Shimano MT400/410
Rear Hub
Shimano MT400/410
Rims
Race Face Aeffect TLR, 27mm, 32H
Spokes
Inox 2.0
Tires
Maxxis Ardent EXO 2.25 F-Ikon EXO 2.25 R
Brakes
Brakes
Front: Shimano XT 180mm, Rear: Shimano XT 180mm
Cockpit
Stem
BH FIT 60mm, 31,8mm, -6º
Handlebar
BH SL Top Flat 780mm, 10mm Rise
Grips
BH Control Grip
Headset
Acros ICR FIT 36/45º, Block Lock 160º
Seat
Saddle
Prologo Scratch M5
Seatpost
BH SL 31,6mm 420mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.504 mm | 1.437 mm | 1.393 mm | 1.402 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 682 mm | 703 mm | 733 mm | 754 mm |
| Rake | 59 mm | 51 mm | 53 mm | 49 mm |
| Trail | 84 mm | 96 mm | 94 mm | 98 mm |
| Stack | 605.5 mm | 610.1 mm | 624.1 mm | 648.5 mm |
| Reach | 402.5 mm | 424.5 mm | 448 mm | 462.5 mm |
| Top Tube Length | 580 mm | 595.5 mm | 629.4 mm | 648.5 mm |
| Seat Tube Angle | 74.2 ° | 74 ° | 74 ° | 73.8 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 545 mm |
| Head Tube Angle | 68.5 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1093 mm | 1114 mm | 1145 mm | 1165 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
ULTIMATE EVO 8.5 completes the Bh Ultimate model. 45 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the BH ULTIMATE RC 6.5 2023 has a starting price of 2249$. BH ULTIMATE 9.9 2023 on the other hand is the most expensive at 10095$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 4986$. Doing a quick comparison, we notice that ULTIMATE EVO 8.5 price is 161.73% higher than the average cost of a Crosscountry bike.
Overview of components
Fork
This bike has the Fox Factory Float 34 fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the ULTIMATE EVO 8.5 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
