Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Battery Shimano Battery SM-BTR2 -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aquila Time Trial Countervail carbon
Suspension Fork
Bianchi Countervail full carbon
Drivetrain
Rear Derailleur
Shimano Dura Ace Di2, 11 spd
Front Derailleur
Shimano Dura Ace Di2
Shift Levers
Shimano Dura Ace Di2 TT
Cassette
Shimano Dura Ace, 11-25T
Crank
Shimano Dura Ace, 52/36T
Bottom Bracket
Shimano PressFit
Chain
Shimano Dura Ace 11 spd
Wheels
Tires
Vittoria Rubino Pro Speed 700x25c
Brakes
Brakes
Bianchi Aero-860-BI
Cockpit
Stem
included in the handlebar
Handlebar
Bianchi Aero Carbon Fully Integrated w/bar ends
Headset
FSA
Seat
Saddle
Fi'zi:k Tritone K:ium
Seatpost
Bianchi Aero Carbon
Motor & Battery
Battery
Shimano Battery SM-BTR2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.278 mm | 1.221 mm | 1.235 mm | 1.25 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 563 mm | 590 mm | 618 mm | 645 mm |
| Rake | 45 mm | 44 mm | 44 mm | 44 mm |
| Trail | 62 mm | 63 mm | 63 mm | 63 mm |
| Stack | 483 mm | 492 mm | 521 mm | 550 mm |
| Reach | 378 mm | 403 mm | 422 mm | 440 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 80 mm | 90 mm | 120 mm | 150 mm |
| Chainstay Length | 398 mm | 398 mm | 398 mm | 398 mm |
| Wheelbase | 949 mm | 976 mm | 1004 mm | 1031 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Aquila CV Dura Ace Di2 is part of the Bianchi Aquila model. 22 bikes variations carry this model name so far. You can get a glimpse at all models from 2016, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Triathlon bikes
If you want to purchase a solid Triathlon bike, it is important to know that the average cost is 4177$. However, even though the average price of a Triathlon bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Aquila CV Dura Ace Di2 components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The Aquila CV Dura Ace Di2 2016 bike is equipped with 700c wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Aquila CV Dura Ace Di2 has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, it won’t take much to find one that’s right for you.
