Bianchi e-Vertic X-Type Deore 2023
2023 E-bike
Estimate price |
4,281$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Suntour XCR Air
-
Groupset Deore, FSA -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Powertube 625Wh integrated battery -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
e-VERTIC X-Type ALU sizes: 43, 48, 53 - 9x135 mm quick release dropouts - Post mount 180 disc brake type - 120mm travel front - Internal cable routing in steerer - 625Wh compatible
Suspension Fork
Suntour XCR34-AIR-Boost LOR DS 15QLC32-110 29", 120mm travel, 1.5" tapered HT, Thru Axle 15QLC32-110, minimum 180mm rotor, maximum 203mm rotor, Damper Type LOR, 34mm stanchions, Air
Drivetrain
Rear Derailleur
Shimano, RD-M4120, DEORE, SGS 10/11-SPEED
Shift Levers
Shimano, SL-M4100-R, DEORE, 10-SPEED
Crank
FSA CK-320/IS/Gen4 FSA E-Bike Diecast Crankset ISIS / 165mm / Die cast aluminum, FSA Steel MegaTooth Chainring 34T
Bottom Bracket
included in the motor
Chain
KMC e10S NPBK
Wheels
Front Hub
Formula CL-811 for Center Lock, 32h, 15x110mm TA
Rear Hub
Formula CL-1422, CENTER LOCK, FOR SHIMANO MTB 8/ 9/ 10/ 11-SPEED - O.L.D. 135 mm - AXLE 145 mm
Rims
Velomann E-Sport Tubeless Ready 29", 622x25, 32 hole
Tires
Chaoyang Phantom dry 29x2.3, 60tpi
Brakes
Brakes
Promax DSK-925
Cockpit
Stem
Velomann Viper0, 60mm, 31.8 mm, 1"1/8
Handlebar
Velomann, width 740mm, diam 31.8mm, rise 15mm, backsweep 9°
Grips
T-One Rock T-GP34 single lock grip, TPR, 130mm, plastic inner body, aluminium clamp
Headset
Acros AZF-575 1.8" top / 1.5" - internal cable routing
Seat
Saddle
Velomann Gnd Full-fit Start Up, carbon steel rail, 262x145
Seatpost
Velomann, diam.31,6mm, 0mm seatback, 300mm size 43 350mm size 48 400mm size 53
Motor & Battery
Motor
Bosch Performance Line CX, 250W, 85Nm, Purion display
Battery
Bosch Powertube 625Wh integrated battery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.43 mm | 1.42 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm |
| Front Center | 723 mm | 745 mm | 766 mm |
| Rake | 46 mm | 46 mm | 45 mm |
| Trail | 109 mm | 109 mm | 110 mm |
| Stack | 621 mm | 630 mm | 644 mm |
| Reach | 422 mm | 440 mm | 455 mm |
| Top Tube Length | 595 mm | 616 mm | 634 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm |
| Chainstay Length | 471 mm | 471 mm | 471 mm |
| Wheelbase | 1191 mm | 1213 mm | 1233 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
e-Vertic X-Type Deore belongs to the Bianchi E E Vertic model. 27 e-bikes variations carry this model name so far. Take a sneak peek at all Bianchi E E Vertic e-bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Bianchi e-Vertic C-Type X5 2023 has a starting price of 3161$. Bianchi e-Vertic FX-Type Pro GX AXS 2023 on the other hand is the most expensive at 9243$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail e-bikes
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 3891$. If we compare this with the average Trail e-bike cost we notice that the price is 15.63% higher.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This e-bike has the Suntour XCR Air fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The e-Vertic X-Type Deore 2023 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
