Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Oltre XR.4 Carbon w/Countervail, mechanical/electronic shifting compatible, headset 1.1/8">1.1/4", direct mount brakes, BB PressFit 86.5x41mm
Drivetrain
Bottom Bracket
BB86/BB92, 86.5mm, press-fit
Brakes
Brakes
Not Included
Cockpit
Stem
Not Included
Handlebar
Not Included
Headset
FSA Orbit C-33 Matt UD Carbon 1.1/8">1.1/4", 45°-45° ACB bearings, w/Carbon custom cap for standard stem, for 47mm/52mm OD head tube, NO.44/CF-R/5D
Seat
Seatpost
Oltre Full Carbon Aero, clamp with alloy head adjustable and reversible +/-35mm, setback 25mm/+10mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 53cm | 55cm | 57cm | 59cm | 61cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.3 mm | 1.3 mm | 1.36 mm | 1.38 mm | 1.41 mm | 1.44 mm | 1.49 mm |
| Bottom Bracket Height | 278 mm | 278 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 579 mm | 581 mm | 582 mm | 588 mm | 593 mm | 603 mm | 607 mm |
| Rake | 44 mm | 44 mm | 42 mm | 43 mm | 42 mm | 43 mm | 42 mm |
| Trail | 72 mm | 66 mm | 65 mm | 61 mm | 59 mm | 58 mm | 59 mm |
| Stack | 493 mm | 502 mm | 528 mm | 544 mm | 560 mm | 579 mm | 598 mm |
| Reach | 380 mm | 387 mm | 388 mm | 393 mm | 398 mm | 401 mm | 402 mm |
| Top Tube Length | 518 mm | 528 mm | 538 mm | 553 mm | 563 mm | 578 mm | 588 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 105 mm | 110 mm | 125 mm | 140 mm | 155 mm | 175 mm | 195 mm |
| Chainstay Length | 403 mm | 403 mm | 409 mm | 410 mm | 410 mm | 412 mm | 414 mm |
| Wheelbase | 975 mm | 977 mm | 981 mm | 988 mm | 993 mm | 1005 mm | 1012 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Oltre XR4 Frameset is a Bianchi Oltre model. Bianchi launched 88 frames of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Aero frames
According to our calculations, the average cost of an Aero frame that is reliable is 2657$. However, you could also get a good Aero frame even if you pay a lower amount than the average price. In conclusion, always check frame reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2018 for 4500$. Comparing this to the average Aero frame price, we see that the price is 69.36% higher.
Oltre XR4 Frameset components
Fork material
When it comes to the fork, this frame has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
