Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED eTAP -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Oltre XR.4 Carbon w/Countervail
Suspension Fork
Bianchi Full Carbon Aero w/Countervail, 1.1/8>1.1/4" integrated head
Drivetrain
Rear Derailleur
SRAM Red eTap short cage
Front Derailleur
SRAM Red eTap
Shift Levers
SRAM Red eTap
Cassette
SRAM Red, 11sp 11-28T
Crank
SRAM Red, carbon crank arms, 50/34T
Bottom Bracket
SRAM BB PFGXP PressFit 86.5
Chain
SRAM Red 11sp
Wheels
Tires
Vittoria Corsa G+, 700x25c
Brakes
Brakes
Shimano Dura Ace BR-R9110 direct mount
Cockpit
Stem
Included w/handlebar
Handlebar
Vision Metron 5D Integrated Aero Bar with integrated stem
Headset
FSA Orbit C-33
Seat
Saddle
Fi'zi:k Arione R1
Seatpost
Bianchi Oltre Full Carbon Aero
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 53cm | 55cm | 57cm | 59cm | 61cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.3 mm | 1.3 mm | 1.36 mm | 1.38 mm | 1.41 mm | 1.44 mm | 1.49 mm |
| Bottom Bracket Height | 278 mm | 278 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 579 mm | 581 mm | 582 mm | 588 mm | 593 mm | 603 mm | 607 mm |
| Rake | 44 mm | 44 mm | 42 mm | 43 mm | 42 mm | 43 mm | 42 mm |
| Trail | 72 mm | 66 mm | 65 mm | 61 mm | 59 mm | 58 mm | 59 mm |
| Stack | 493 mm | 502 mm | 528 mm | 544 mm | 560 mm | 579 mm | 598 mm |
| Reach | 380 mm | 387 mm | 388 mm | 393 mm | 398 mm | 401 mm | 402 mm |
| Top Tube Length | 518 mm | 528 mm | 538 mm | 553 mm | 563 mm | 578 mm | 588 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 105 mm | 110 mm | 125 mm | 140 mm | 155 mm | 175 mm | 195 mm |
| Chainstay Length | 403 mm | 403 mm | 409 mm | 410 mm | 410 mm | 412 mm | 414 mm |
| Wheelbase | 975 mm | 977 mm | 981 mm | 988 mm | 993 mm | 1005 mm | 1012 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Oltre XR4 Red eTap belongs to the Bianchi Oltre model. 88 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
The most economical model, the Bianchi Oltre XR3 Ultegra 2018 has a starting price of 3900$. Bianchi Oltre XR4 Red eTap 2018 on the other hand is the most expensive at 10800$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Aero bikes average price
If you want to purchase a solid Aero bike, it is important to know that the average cost is 4211$. However, this doesn’t mean that if you spend less money on an Aero bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Bianchi released this model in 2018, its price was 10800$. Comparing the average cost of an Aero bike to this one, you will see that Oltre XR4 Red eTap price is 156.47% more expensive.
Oltre XR4 Red eTap components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The Oltre XR4 Red eTap 2018 bike is equipped with 700c wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Oltre XR4 Red eTap comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
