Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orso steel, flat mount disc, thru axle 12x142mm, compatible with 42mm tire, mudguard and rear carrier ready
Suspension Fork
Bianchi Alu/Carbon 1.4" - 1.1/8", flat mount disc, thru axle 12x100mm
Drivetrain
Rear Derailleur
Shimano 105 11sp
Front Derailleur
Shimano 105
Shift Levers
Shimano 105 11sp for hydraulic disc brake
Cassette
Shimano 105 11-32T
Crank
Shimano 105 Hollowtech II 50x34T
Bottom Bracket
Shimano BB-RS500
Chain
KMC X11
Wheels
Front Hub
Formula CL-712 12x100mm thru-axle
Rear Hub
Formula RXC-142S 12x142mm thru-axle
Tires
Kenda Flintridge 700x40
Brakes
Brakes
Shimano RS505 flat mount, hydraulic disc brake
Brake Levers
included w/shifters
Disk Rotors
Shimano RT70 Center Lock with Ice Technology 160mm
Cockpit
Stem
Bianchi 3D Forged Alloy
Handlebar
Bianchi Alloy
Headset
Fsa NO.11 / Bianchi
Seat
Saddle
WTB Speed V Sport SE
Seatpost
Bianchi Alloy 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 51cm | 53cm | 55cm | 57cm | 59cm | 61cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.51 mm | 1.5 mm | 1.53 mm | 1.54 mm | 1.56 mm | 1.57 mm | 1.6 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 588 mm | 594 mm | 599 mm | 600 mm | 601 mm | 610 mm | 619 mm | 623 mm |
| Rake | 50 mm | 51 mm | 50 mm | 51 mm | 51 mm | 50 mm | 49 mm | 49 mm |
| Trail | 66 mm | 65 mm | 66 mm | 62 mm | 56 mm | 57 mm | 58 mm | 55 mm |
| Stack | 538 mm | 547 mm | 552 mm | 563 mm | 577 mm | 591 mm | 605 mm | 622 mm |
| Reach | 361 mm | 363 mm | 367 mm | 368 mm | 374 mm | 380 mm | 385 mm | 389 mm |
| Top Tube Length | 506 mm | 516 mm | 521 mm | 531 mm | 546 mm | 556 mm | 571 mm | 586 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 71 ° | 72 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 100 mm | 110 mm | 115 mm | 125 mm | 135 mm | 150 mm | 165 mm | 180 mm |
| Chainstay Length | 426 mm | 426 mm | 431 mm | 431 mm | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1003 mm | 1009 mm | 1019 mm | 1020 mm | 1026 mm | 1035 mm | 1044 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Orso 105 completes the Bianchi Orso model. There are 6 bikes that carry this model name. You can easily view all of the Bianchi Orso bikes models from 2018, here.
Model range prices
Bianchi Orso Sora 2018 is the most affordable bike of this model and has a price of 1300$. On the other hand, Bianchi Orso 105 2018, is the most expensive and costs 2100$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2018 and its price was 2100$. In conclusion, this bike price is 17.24% lower than the price of the average Gravel bike.
Overview of components
Fork material
Orso 105 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Bianchi Orso 105 2018, has a 700c model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Bianchi Orso 105 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
